Поз.
Артикул
Описание
8
FUEL TANK FRONT,5 1810165 436226
8
FUEL TANK200 L
11
SCREW PLUG FUEL TANK
11
SCREW PLUG , Replaced By: N007604014110
14
SEAL RING FUEL LINE TO FEED PUMP
17
FILLER CAP
17
FILLER CAP , Replaced By: A0004700305
17
FILLER CAP , Replaced By: A0004700305
17
FILLER CAP , Replaced By: A0004700305
20
SEAL RING
23
CHAIN FILLER CAP
29
FUEL STRAINER FUEL TANK,K 169123
29
FUEL STRAINER FUEL TANK,K 169122
35
SENDER UNIT FUEL GAUGE
38
SENDER UNIT , NOT USED
38
SENDER UNIT FUEL GAUGE,K 169123
41
PLUG TO SEAL AUXILIARY HEATER CONNECTION 8 MM,K 169123
44
SEAL RING FUEL GAUGE SENDER UNIT TO FUEL TANK
47
CONNECTOR FEED LINE AND RETURN LINE 11X1,5 MM
47
CONNECTOR FEED LINE AND RETURN LINE 12,5X1,25 MM
47
CONNECTOR FEED LINE AND RETURN LINE 8X1 MM
50
GASKET KIT CONNECTION ON FUEL GAUGE SENSOR
53
LOCK FUEL GAUGE SENDER UNIT CONNECTION
65
SUPPORT FRONT
68
SUPPORT FRONT
71
SUPPORT REAR
74
PIN BRACKET TO CONSOLE,5 164311
77
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
77
SCREW , Replaced By: N304017008016
80
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
83
SHIM SUPPORT TO SIDE MEMBER
86
SHIM SUPPORT TO SIDE MEMBER
92
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
95
SCREW STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
101
WASHER SPARE WHEEL CARRIER
104
WASHER HELPER SPRING BRACKET TO SIDE MEMBER,5 201989 UP TO IDENT NO. 5 319597,FROM IDENT NO. SEE STANDARD VERSION
107
NUT SUPPORT TO SIDE MEMBER
110
NUT BRACKET TO SIDE MEMBER
110
NUT , Replaced By: N910113014001
116
STRAP FRONT AND REAR BRACKETS,5 149420
125
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
128
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
131
CONICAL SOCKET. CONICAL CUP REAR STRAP
134
SPHERICAL WASHER REAR STRAP
140
NUT STRAP TO SUPPORT
