Поз.
Артикул
Описание
7
BRACKET LEFT TAIL LAMP,K 062690
7
BRACKET RIGHT TAIL LAMP,K 062690
13
BRACKET LEFT TAIL LAMP
13
BRACKET RIGHT TAIL LAMP
19
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
19
SCREW , Replaced By: N304017008016
23
WASHER , Replaced By: N000125008443
23
WASHER EXHAUST MUFFLER TO STRAP
27
NUT , Replaced By: N913004008001
27
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
33
BRACKET TAIL LAMP BRACKET
38
BRACKET TAIL LAMP BRACKET
38
BRACKET
42
BASE TAIL LAMP BRACKET TO FRAME,K 062691
47
SCREW BRACKET TO CAB CONSOLE,K 035197
47
SCREW STRUT TO FRAME M 14X1.5X42
53
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
53
WASHER , Replaced By: N000125015019
58
NUT , Replaced By: N910113014001
58
NUT BRACKET TO SIDE MEMBER
63
BRACKET , Replaced By: A6735256039
63
BRACKET LICENSE PLATE
70
BRACKET REFLECTOR
74
SCREW LICENSE PLATE TO BRACKET
74
SCREW , Replaced By: N304017006020
78
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
78
WASHER COMPRESSED AIR LINE TO BRACKET
82
NUT , Replaced By: N913004006001
82
NUT PUMP TO BRACKET
86
REFLECTOR
89
SCREW JUNCTION BOX TO BRACKET
93
WASHER BOOT TO CAB FLOOR
93
WASHER , Replaced By: N000433005304
96
NUT TWO-WAY VALVE TO BRACKET
101
NAME PLATE
106
RIVET NAME PLATE TO TAIL LAMP BRACKET
112
BRACKET GUIDE CROSS
115
SCREW , Replaced By: N304017010002
115
SCREW BRACKET TO SIDE MEMBER
115
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
121
NUT STRAP TO BRACKET
121
NUT , Replaced By: N910113010000
127
BRACKET REFLECTOR
133
SIDE MARKER LAMP
133
SIDE MARKER LAMP , Replaced By: A0005442311
137
BULB24 V
143
REFLECTOR FENDER
143
REFLECTOR REAR LEFT AND RIGHT
143
REFLECTOR AMBER
146
RIVET REFLECTOR TO BRACKET
152
SCREW CLAMP MOUNTING M 6X16
152
SCREW , Replaced By: N000000001146
157
SCREW , Replaced By: A0029903712
157
SCREW , Replaced By: N000000001149
157
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
162
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
162
WASHER COMPRESSED AIR LINE TO BRACKET
167
NUT , Replaced By: N913004006001
167
NUT PUMP TO BRACKET
999
BRACKET ,K 062691K 251255
999
BRACKET ,K 062691K 251255
