Поз.
Артикул
Описание
5
CROSS MEMBER COUPLING MOUTH
11
NUT , Replaced By: N910113012003
14
GUSSET PLATE LEFT
14
GUSSET PLATE RIGHT
17
SCREW BRACKET TO FRAME M 12X35
17
SCREWM 12X12X17X32
20
NUT FRONT SPRING FRONT BRACKET TO SIDE MEMBER
23
FRAME COUPLING MOUTH, NOT INCLUDED IN RANGE OF DELIVERY OF: 684 310 07 01,01 01,02 01,08 01,03 01,04 01
26
SEALING CORD FOR COUPLING MOUTH
29
LOCKING SPRING TO SECURE COUPLING PIN
32
SCREW SHIFT LEVER BEARING TO CAB FLOOR,K 040603
35
WASHER TRAILER PLUG SOCKET TO BRACKET
38
NUT , Replaced By: N913004008001
41
FRONT SPRING BRACKET FRONT AND REAR
47
SCREW PLATE TO SIDE MEMBER
50
NUT , Replaced By: N910113014000
53
PLATE HELPER SPRING
59
FRONT SPRING BRACKET LEFT AND RIGHT, TO BE ADAPTED DURING ASSEMBLY
59
FRONT SPRING BRACKET LEFT AND RIGHT, TO BE ADAPTED DURING ASSEMBLY
62
SCREW SPRING BRACKET TO SIDE MEMBER, NOT INCLUDED IN RANGE OF DELIVERY OF: 684 310 07 01,01 01,02 01,08 01,03 01,04 01
65
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
68
CROSS MEMBER TRANSMISSION MOUNTING
999
SCREWM 12X12X11X26
