Поз.
Артикул
Описание
5
BRAKE LEVER
5
BRAKE LEVER ,D 001917
5
BRAKE LEVER ,D 001917
8
PAWL ROD ,D 001917
11
HANDLETO 6844200012,D 001917
11
HANDLETO 6844200012,D 001917
11
HANDLE
12
ROD ,D 001918
14
CLAMPING SLEEVETO 6844200012,D 001917
17
BRACKET
17
BRACKET ,D 001917
20
PAWL ,D 001917
21
PAWL ,D 001918
23
SCREW BRAKE LEVER TO BEARING BRACKET M 8X20
26
NUT BRACKET TO BRACKET
27
PIN ,D 001918
27
PIN ,D 001917
30
WASHER , Replaced By: N000433005304
30
WASHER BOOT TO CAB FLOOR
32
SPRING ,D 001917
33
SPRING
35
GROOVED PIN
38
SWITCH
41
SCREWM 2X10
44
NUT SPRING-LOADED PUSH ROD
47
SCREW BRACKET TO BATTERY/APPARATUS SUPPORT
47
SCREW BRAKE LEVER TO BEARING BRACKET M 8X20
50
LOCK WASHER RAIL TO BATTERY SUPPORT
53
NUT BRACKET TO BRACKET
56
BRAKE LEVER PARKING BRAKE
59
BUSHING BRAKE CABLE TO BRAKE LEVER
62
PIN BRAKE CABLE TO BRAKE LEVER
62
PIN BRAKE CABLE TO BRAKE LEVER
65
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
66
BRACKET AT SIDE MEMBER
68
BRACKET AT SIDE MEMBER
71
SCREW , Replaced By: N910105010009
72
SCREW STRUT TO CROSS MEMBER M 10X25
74
NUT EXHAUST PIPE TO SIDE MEMBER
75
NUT CROSS MEMBER TO SIDE MEMBERS
76
CLAMP , Replaced By: N916016010211
77
SCREW OIL DELIVERY LINE TO BRACKET
78
NUT HEATING PIPE TO BRACKET
79
SPRING BRAKE LEVER
80
EDGE GUARD SECTION , Replaced By: A0019872272
80
EDGE GUARD SECTION , Replaced By: A0029878872
83
SCREW BRACKET TO BEARING BRACKET,K 274033
86
WASHER HAND BRAKE LEVER TO SIDE MEMBER
89
WASHER BRACKET TO BRACKET
92
NUT EXHAUST PIPE TO SIDE MEMBER
95
BRAKE CABLE FRONT
95
BRAKE CABLE FRONT
98
BRAKE CABLE REAR
99
SPRING
101
GROMMET CLUTCH LINE TO BRACKET
104
NUT ANGLE TO FRAME
107
WASHER HAND BRAKE CABLE
107
WASHER PROPELLER SHAFT TO BRACKET
110
BUSHING BRAKE CABLE TO BRACKET
113
SPRING BRAKE CABLE TO BRACKET
116
NUT
128
BRAKE DRUM PARKING BRAKE, INCLUDED IN RANGE OF DELIVERY OF: A 684 260 42 01, 43 01, 52 01
