Поз.
Артикул
Описание
5
BODY SUPPORT CAB SUSPENSION,FRONT
5
BODY SUPPORT CAB SUSPENSION,FRONT
8
BEARING BRACKET LEFT BOTTOM
8
CONSOLE LEFT BOTTOM
11
CONSOLE RIGHT BOTTOM
11
CONSOLE RIGHT BOTTOM
14
CONSOLE LEFT TOP
17
RUBBER BUFFERTO 684 310 10 63, 684 310 09 63
20
CONSOLE RIGHT TOP
23
BUSHING
26
LEVER CAB SUSPENSION
29
TORSION BAR CAB SUSPENSION
32
SCREW BRACKET TO EXHAUST PIPE BRACKET
35
WASHER CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
38
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
41
SPACER TUBE TORSION BAR TO CONSOLE
44
LOCK WASHER FITTING TO BRACKET
47
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBERM 12X1.5X30
47
HEXAGON HEAD BOLT. SCREW RUBBER BUFFER TO SUPPORT M 12X90
53
WASHER TORSION BAR TO CONSOLE
56
SPACER WASHER AS REQUIRED 3,00MM
56
SPACER WASHER AS REQUIRED 2,00MM
56
SPACER WASHER AS REQUIRED 1,00MM
59
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M12X45
62
WASHER , Replaced By: N007349013003
65
NUT BRACKET TO SIDE MEMBER M12X1.5
66
BRACKET CAB SUSPENSION
68
PLATE CAB SUSPENSION,FRONT RIGHT
