Поз.
Артикул
Описание
47
BUSHING CONTROL LEVER,B 892892
83
WIRE CABLE IDLING ADJUSTMENT
83
WIRE CABLE MANUAL IDLING CONTROL
84
GROMMET ,D 314239
89
BRACKET IDLING ADJUSTMENT,B 990550010626
92
SCREW SWITCH TO BRACKET 8X16
95
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
98
SPHERICAL WASHER WIRE CABLE TO LEVER,B 990550
101
NUT ,B 884219
125
CLAMP LINE MOUNTING
128
SCREW
128
SCREW BRACKET MOUNTING
131
NUT TWO-WAY VALVE TO BRACKET
134
LEVER ACCELERATOR CONTROL
137
BUSHING , USED WITH AIR BRAKE
140
SPRING DOUBLE LEVER,D 208694
143
FITTED WASHER , USED WITH AIR BRAKE
146
GREASE NIPPLE
149
BALL PIVOT
152
BALL PIVOT LEVER
155
BRACKET DOUBLE LEVER,010627
158
PIN DOUBLE LEVER,010627
161
HEXALOBULAR BOLT. SCREW CLAMP ON BRACKET M 8X60
164
NUT HORN TO BRACKET M8
167
PULL ROD FROM INTERMEDIATE LEVER II TO REAR CONTROL SHAFT 6X360X30/30
170
BALL SOCKET PULL ROD TO LEVER
173
NUT SPRING-LOADED PUSH ROD
176
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
