Поз.
Артикул
Описание
5
BRAKE VALVE (SERVICE BRAKE VALVE) WABCO
5
BRAKE VALVE (SERVICE BRAKE VALVE) BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
BRAKE VALVE (SERVICE BRAKE VALVE) KNORR
5
BRAKE VALVE (SERVICE BRAKE VALVE) GRAU
8
VALVEWABCO
11
FILLER RINGTO 001 431 83 05,WABCO
14
BREATHER PIPETO 001 431 83 05,WABCO
17
PISTONTO 001 431 83 05,WABCO
20
SPRINGBOSCH
23
26
BRACKET TRUCK-TRACTOR BRAKE VALVE
29
SCREW , Replaced By: N304017008027
32
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
35
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
38
SCREW PLUG RELAY VALVE
41
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
44
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
47
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
50
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
53
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
56
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
59
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
62
BREATHER PIPE TWO-CIRCUIT BRAKE VALVE BLEEDING
65
VALVE (CHECK VALVE) VOSS
65
VALVE (CHECK VALVE) SCHAEFER
68
VALVE TAPPETTO 002 429 96 44,VOSS
71
SEAL RINGTO 002 429 96 44,VOSS
74
SEAL RING13.6X2 MM,TO 003 429 12 44,SCHAEFER
74
SEAL RING15.3X2.4 MM,TO 003 429 12 44,SCHAEFER
77
THRUST WASHERTO 003 429 12 44,SCHAEFER
80
SEAL CONETO 003 429 12 44,SCHAEFER
86
NUT CHECK VALVE TO AIR RESERVOIR
89
BRACKET HEAT SHIELD
92
SCREW , Replaced By: N304017010002
95
NUT , Replaced By: N910113010000
98
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
101
HOLLOW SCREW , Replaced By: N915036010108
103
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
106
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
109
SEAL RING FUEL LINE TO FEED PUMP
