Поз.
Артикул
Описание
71
CLAMP 3/2-WAY SOLENOID VALVE
74
SCREW CONTROL UNIT
77
WASHER PLUG SOCKET TO BRACKET
80
NUT , Replaced By: N913004006001
116
HOSE FRONT AND REAR AXLE BRAKE CYLINDERS 11 MM
119
UNION NUT LINE CONNECTION, Replaced By: N000000006239
122
GLAND , Replaced By: A0019901967
125
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
125
CLAMP , Replaced By: N000000000667
128
CLAMP BRAKE HOSE
131
CLAMP BRAKE HOSE
134
FITTING
146
FITTING DIAPHRAGM CYLINDER,CONNECTION:
164
ADAPTER FITTING , Replaced By: A0004296934
167
NUT SHIFTING ROD UNLOCKING HIGH-PRESSURE HOSE
170
T-FITTING LEFT AND RIGHT BRAKE HOSES
173
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
176
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
179
FITTING DELIVERY LINE TO PUMP
182
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
185
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
191
ADAPTER FITTING , Replaced By: A0069970072
194
T-FITTING AIR RESERVOIR,CONNECTION: "31"
197
NUT COMBINATION CYLINDER,CONNECTION: "12"
200
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
203
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
206
TEST CONNECTION
206
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
206
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
206
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
