Поз.
Артикул
Описание
5
PUMP (HAND PUMP) WEBER
8
PUMP , Replaced By: A0005536501
11
PISTONTO 000 553 79 01,WEBER
14
VALVETO 000 553 39 01,WEBER
17
SCREW , Replaced By: N000000000190
20
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
23
FILTER
26
FITTED WASHER
29
LOCK RING
32
SCREW
35
SCREWTO 000 553 65 01,000 553 69 01,
38
GASKET KIT HAND PUMP
41
REPAIR KIT VALVE TO 000 553 54 01,POWER-PACKER,4 733732
41
REPAIR KIT PISTON TO 000 553 54 01,POWER-PACKER,4 733732
44
BRACKET HAND PUMP
50
SCREW , Replaced By: N304017010002
53
NUT , Replaced By: N910113010000
56
SCREW BRACKET TO BATTERY CASE
59
NUT , Replaced By: N910113014001
