Поз.
Артикул
Описание
5
RESERVOIR FLUID RESERVOIR
8
FILLER CAPTO A 688 431 00 02
11
STRAINER
14
NUT CONTROL ARM TO REAR AXLE
17
MASTER CYLINDER , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0012955206, +001A6732900439
17
MASTER CYLINDER CLUTCH M14X1,D 561822
17
MASTER CYLINDER , Replaced By: A0012959706
20
PLUG
23
CYLINDER. REPAIR KIT CLUTCH MASTER CYLINDER,5 366604
26
INTERMEDIATE PIECE , Replaced By: A0002950036
29
SCREW
32
ROD CLUTCH PEDAL
35
BRAKE HOSE. HOSE FROM RESERVOIR TO MASTER CYLINDER
38
CLAMP LINE MOUNTING
41
LINE FROM CLUTCH MASTER CYLINDER TO CLUTCH HOSE
96
CLAMP ,K 147121, Replaced By: N000000000319
117
PART NAME MISSING SCREW 5/16-18
120
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
