Поз.
Артикул
Описание
5
REAR SPRING
8
PIN SPRING TO BEARING, INAPPLICABLE TO BM 685.441-327,310 BM 685.448-310
11
PART NAME MISSING COTTER PIN 1/8X1 3/4, INAPPLICABLE TO BM 685.441-327,310 BM 685.448-310
14
BUSHING , INAPPLICABLE TO BM 685.441-327,310 BM 685.448-310
17
PART NAME MISSING SCREW 1-8 X 5 FG8
20
PART NAME MISSING NUT 1-8 CAD G8, INAPPLICABLE TO BM 685.441-327,310 BM 685.448-310
23
CLAMP REAR SPRING TO REAR AXLE
26
SPACER
29
BRACKET REAR SPRING TO REAR AXLE
29
BRACKET REAR SPRING TO REAR AXLE
35
PAD REAR SPRING TO REAR AXLE
41
WASHER SHIM TO AXLE 3/4
44
PART NAME MISSING NUT 3/4-16, INAPPLICABLE TO BM 685.441-327,310 BM 685.448-310
