Поз.
Артикул
Описание
62
CLAMP COMPRESSED AIR LINE TO CROSS MEMBER
65
SCREW HAND BRAKE VALVE 1/4-20
68
WASHER HAND BRAKE VALVE 1/4
71
NUT COMPRESSED AIR LINE TO CROSS MEMBER1/4,M 033721
74
SPACER TUBE
80
LOOM TIE
80
LOOM TIE LINE MOUNTING
80
LOOM TIE
88
CLAMP
89
BRAKE HOSE3/8-1/4,LG610
89
BRAKE HOSE3/8-1/4,LG610
110
BRAKE HOSE FROM RELAY VALVE TO COMBINATION CYLINDER 3/8-3/8 - 838 MM
110
BRAKE HOSE FROM RELAY VALVE TO COMBINATION CYLINDER 3/8-3/8,LG1015
110
BRAKE HOSE FROM RELAY VALVE TO COMBINATION CYLINDER 3/8-3/8,LG1015, Replaced By: A6854291335
110
BRAKE HOSE FROM RELAY VALVE TO COMBINATION CYLINDER 3/8-3/8,LG838, Replaced By: A6854291235
113
FITTING3/8 NPT
116
WASHER
119
NUT1-14
999
HOSEPH 63NTA4
999
HOSEPH 60NTA4
