Поз.
Артикул
Описание
5
FRAME
5
8
CROSS MEMBER , Replaced By: A6883107222
11
11
COUPLING PIN ,B 981820
14
LOCKING SPRING TOP,B 981820
17
LOCKING SPRING BOTTOM
20
REAR SUBFRAME (FRONT SPRING BRACKET),FRONT
23
SCREW SUPPORT TO SIDE MEMBER M 12X1.5X35
26
NUT ALTERNATOR TO SUPPORT
29
REAR SUBFRAME (FRONT SPRING BRACKET),REAR
29
REAR SUBFRAME , Replaced By: A6883207070
32
CROSS MEMBERNO.2,D 012825
35
SCREW BRACKET TO FRAME M 10X28
35
SCREW HAND PUMP TO BRACKET
36
SCREW BRACKET TO BUMPER,LEFT M 10X25
38
NUT BRACKET TO SIDE MEMBER,XB209706
41
CROSS MEMBERNO. 3
44
CROSS MEMBER PROPELLER SHAFT BEARING NO.4,B 905494B 984609
44
CROSS MEMBER
47
CROSS MEMBER REAR SPRING FRONT BRACKET NO. 4
50
BRACKET
53
BRACKET
56
SPRING BRACKET (REAR SPRING BRACKET),FRONT
59
CROSS MEMBER SHOCK ABSORBER NO.7
59
CROSS MEMBER SHOCK ABSORBER NO.6
65
CONSOLE , Replaced By: A6883117063
68
BRACKET HELPER SPRING
68
BRACKET HELPER SPRING
71
SPRING BRACKET (REAR SPRING BRACKET),REAR M18X1,5 MM
74
CROSS MEMBER825 MM
83
83
RIVET CONSOLE TO SIDE MEMBER
83
RIVET10X36 MM
83
RIVET CROSS MEMBER TO SIDE MEMBERS 10X30 MM, TO BE ADAPTED DURING ASSEMBLY
83
RIVET GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS 10X26 MM
83
RIVET10X28 MM, TO BE ADAPTED DURING ASSEMBLY
83
RIVET12X45 MM
83
RIVET FRAME TRUSS TO SIDE MEMBER
83
RIVET14X40 MM
83
RIVET10X34 MM
83
RIVET REFLECTOR TO BRACKET
83
RIVET14X42 MM
83
RIVET10X24 MM, TO BE ADAPTED DURING ASSEMBLY
83
RIVET REAR CROSS MEMBER 12X42 MM
83
RIVET10X32 MM, TO BE ADAPTED DURING ASSEMBLY
86
BRACKET BUMPER BRACKETS
89
SCREW , Replaced By: N304017010040
92
WASHER GROUND CABLE
999
NUT , Replaced By: N910113010000
