Поз.
Артикул
Описание
5
DISTRIBUTOR BRAKE LINE TO BRAKE MASTER CYLINDER
5
DISTRIBUTOR BRAKE LINE TO BRAKE MASTER CYLINDER
8
HOLLOW SCREW DISTRIBUTOR TO MASTER CYLINDER
11
SEAL RING FUEL LINE TO FEED PUMP
14
LINE FROM BRAKE MASTER CYLINDER TO FRONT AXLE BRAKE HOSE,LEFT,D 070925
17
LINE FROM BRAKE MASTER CYLINDER TO FRONT AXLE BRAKE HOSE,RIGHT,D 070925
20
BRAKE HOSE FRONT AXLE
20
BRAKE HOSE FRONT AXLE
23
RETAINING SPRING BRAKE HOSE TO BRACKET
26
LINE FROM BRAKE HOSE TO LEFT FRONT CALIPER
29
LINE FROM BRAKE HOSE TO RIGHT FRONT CALIPER
49
LINE FROM MASTER CYLINDER TO PRESSURE RETAINING VALVE
52
VALVE , Replaced By: A1214290134
52
VALVE , Replaced By: A1214290134
55
LINE FROM VALVE TO BRAKE HOSE,D 070925
58
BRAKE HOSE REAR AXLE
58
BRAKE HOSE REAR AXLE
61
LINE FROM DISTRIBUTOR TO LEFT WHEEL BRAKE CYLINDER
63
LINE
65
RETAINING SPRING BRAKE HOSE TO BRACKET
68
DISTRIBUTOR REAR AXLE
71
HOSE BRAKE LINE TO CAB SIDE MEMBER,D 065341
74
CLAMP BRAKE LINE MOUNTING
77
BRACKET LINE TO SIDE MEMBER
79
79
79
BRACKET BRAKE LINE TO FIRE WALL
79
BRACKET BRAKE LINE TO FIRE WALL
82
SHEET METAL SCREW BRACKET TO FRAME SIDE MEMBER,D 070925
85
BRACKET BRAKE LINE TO REAR AXLE
88
SCREW , Replaced By: N910143008000
91
BRACKET BRAKE HOSE TO SIDE MEMBER
100
BRACKET COMPRESSED AIR LINES
113
113
CLAMP FUEL LINES TO BRACKET
116
CLAMP ,K 147121, Replaced By: N000000000319
116
CLAMP LINE TO SIDE MEMBER
119
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
119
SCREW , Replaced By: N914146006102
122
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
124
SCREW BRACKET TO CAB REAR PANEL M 8X20
130
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
133
NUT BRACKET TO FIRE WALL
139
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
142
LOCK WASHER CABLE TO FUSE BOX
148
HOSE BRAKE LINE TO CAB SIDE MEMBER,D 065341
163
BRACKET AT RIGHT SIDE MEMBER
