Поз.
Артикул
Описание
70
BRAKE LEVER , NO.8650I.......I.......I I II
73
78
HANDLE , NO.8650I.......I.......I I II .......INO.9985I.......I I II
81
COVERING , NO.8650I.......I.......I I II .......INO.9985I.......I I II
84
87
90
CONSOLE
90
CONSOLE
93
HEXAGON HEAD BOLT. SCREW CLUTCH SLAVE CYLINDER TO BELL HOUSING
96
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
99
HEXAGON HEAD BOLT CONSOLE TO REAR CROSS MEMBER AND TO FRAME SIDE MEMBERS M 10X40
102
WASHER CONSOLE TO CAB
105
WASHER
109
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
112
NUT REINFORCEMENT TO BRACKET
115
118
121
NUT BRAKE CABLE TO BRAKE LEVER
124
BRAKE CABLE FRONT LEFT
127
BRAKE CABLE FRONT RIGHT
130
PIN BRAKE CABLE TO BRAKE LEVER
133
136
GROMMET LINE THRU LEFT SIDE MEMBER
139
SPRING BRAKE CABLE
142
SWITCH HAND BRAKE CONTROL
145
BRACKET , Replaced By: A3464296040
148
BRACKET
152
GUIDE PLATE REAR BRAKE CABLE TO BRACKET
158
CLAMP BATTERY POS. CABLE TO BRACKET
161
SCREW , Replaced By: N914146006102
164
SCREW , Replaced By: N910143008000
167
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
167
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
170
LOCK WASHER CABLE TO FUSE BOX
173
LOCK WASHER RAIL TO BATTERY SUPPORT
176
NUT , Replaced By: N913023006001
179
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
179
NUT ENGINE MOUNTING M8
