Поз.
Артикул
Описание
5
BRAKE LEVER , NO.8650I.......I.......I I II
8
HANDLE , NO.8650I.......I.......I I II .......INO.9985I.......I I II
11
COVERING , NO.8650I.......I.......I I II .......INO.9985I.......I I II
14
COVERING , NO.8650I.......I.......I I II .......INO.9985I.......I I II
17
CONSOLE
17
CONSOLE
20
SCREW CONSOLE TO CAB M 10X80
23
SCREW HAND PUMP TO BRACKET
26
WASHER CONSOLE TO CAB
29
STOP BUFFER. DAMPING RING
32
SCREW CROSS MEMBER TO SIDE MEMBERS
35
WASHER GROUND CABLE
38
NUT , Replaced By: N910113010000
41
COVERING AT CONSOLE, NO.8650I.......I.......I I II .......INO.9985I.......I I II
44
44
BRAKE CABLE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.B 969878, Replaced By: A6884207885
44
BRAKE CABLE FRONT LEFT
44
BRAKE CABLE FRONT LEFT
44
BRAKE CABLE FRONT LEFT
44
44
47
47
47
BRAKE CABLE FRONT RIGHT
47
47
BRAKE CABLE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.B 969878, Replaced By: A6884207985
47
BRAKE CABLE FRONT RIGHT
47
BRAKE CABLE FRONT RIGHT
50
GROMMET
53
SPRING BRAKE CABLE
59
PIN BRAKE CABLE TO BRAKE LEVER
62
NUT BRAKE CABLE TO BRAKE LEVER
68
BRACKET TO ENGINE
71
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT, TO BE ADAPTED DURING ASSEMBLY
74
SCREW STEERING SHAFT BEARING TO CAB M 8X20
75
SCREW BRACKET TO REAR CROSS MEMBER
80
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
83
GUIDE PLATE REAR BRAKE CABLE TO BRACKET
86
SCREW PARKING BRAKE VALVE TO INSTRUMENT PANEL,TB108828
89
LOCK WASHER RAIL TO BATTERY SUPPORT
92
CLAMP DELIVERY AND SUCTION LINES TO FRAME
92
CLAMP BATTERY POS. CABLE TO BRACKET
92
CLAMP DELIVERY AND SUCTION LINES TO FRAME 12/15
95
SCREW CLAMP TO BRACKET
98
WASHER PLUG SOCKET TO BRACKET
101
LOCK WASHER CABLE TO FUSE BOX
104
NUT
107
BRACKET
110
GROMMET LINE THRU LEFT SIDE MEMBER
