Поз.
Артикул
Описание
5
STEERING SUPPORT
8
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBERM 12X1.5X30
8
SCREW LEFT AND RIGHT CONSOLES TO FRAME M 12X1.5X50
14
NUT BRACKET TO SIDE MEMBER M12X1.5
17
HEXAGON HEAD BOLT SUPPORTING ARM TO ENGINE REAR MOUNTING M18X1.5X50
17
SCREW STEERING BOX ASSEMBLY TO STEERING SUPPORT
26
PITMAN ARM
29
BOOT
32
DRAG LINKNAKATA
35
DRAG LINK ENDTO 688 460 81 05
41
BOOT FIXED PART OF JOINT TO 688 460 05 05,75 05,74 05,76 05
47
CLAMPING PIECE JOINT TO DRAG LINK TO 688 460 05 05,75 05,81 05, 7605
47
CLAMP JOINT TO DRAG LINK TO 688 460 05 05,75 05,81 05, 7605
50
SCREW CLAMP TO DRAG LINK TO 000 463 05 17
53
NUT , Replaced By: N910113010003
65
NUT DRAG LINK TO STEERING ARM AND PITMAN ARM TO 688 460 81 05
68
COTTER PINROCKINGER TYP 260 G140
