Поз.
Артикул
Описание
11
BEARING BRACKET , Replaced By: A3842947201
11
BEARING BRACKET BRAKE PEDAL
14
BEARING BRACKET , Replaced By: A6882947001
20
GASKET BEARING BRACKET TO CAB
23
GASKET BEARING BRACKET TO CAB
29
STUD ,D 001959 AS OF PRODUCTION BREAKPOINT DATE 01.2004NAO 16/02N06
29
STUD
32
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
35
NUT BRACKET TO FIRE WALL
41
NUT HORN TO BRACKET M8
48
BRACKET SERVICE BRAKE VALVE
48
BRACKET SERVICE BRAKE VALVE
50
STUDM 8
50
STUD COVER TO SHIFT CASE
51
GASKET BRAKE SHOE WITH LINING
51
GASKET BRAKE BOOSTER ASSEMBLY TO FIRE WALL
53
STOP CLUTCH PEDAL
56
STOP CLUTCH PEDAL STOP
56
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
59
NUT HORN TO BRACKET M8
71
71
PEDAL (CLUTCH PEDAL)
71
74
NEEDLE BEARING CLUTCH PEDAL
74
NEEDLE BEARING
77
77
PIN CLUTCH PEDAL39 MM(M10) TO A6952907216
80
NUT AIR CLEANER ELEMENT
83
PAD , Replaced By: A1072910182
84
PIN
84
85
WASHER
87
87
95
WASHER CLUTCH PEDAL TO BEARING BRACKET
101
PIN CLUTCH PEDAL TO BEARING BRACKET
104
LOCK CLUTCH AND BRAKE PEDAL PINS TO BEARING BRACKETS
107
SCREW CLAMP MOUNTING M 6X16
146
STOP BRAKE PEDAL
146
STOP
158
PEDAL BRAKE, NO.8650I.......I I I II .......INO.9985I I I II I
161
PAD , Replaced By: A1072910182
164
BUSHING , Replaced By: A1242920050
170
PIN CLUTCH PEDAL TO BEARING BRACKET
173
SPACER WASHER BRAKE PEDAL TO BEARING BRACKET
176
SPRING BRAKE PEDAL TO BEARING BRACKET
179
LOCK CLUTCH AND BRAKE PEDAL PINS TO BEARING BRACKETS
185
SCREW BRACKET TO COVERING
191
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
197
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
203
WASHER 10,5 DIN 433. WASHER , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
209
COTTER PIN PISTON ROD TO BRAKE PEDAL 3,2X20
224
ROD FROM FITTING TO CLUTCH BOOSTER
230
YOKE
236
NUT BRACKET TO SIDE MEMBER M12X1.5
245
SPRING PARTS KIT
245
ROD , Replaced By: A3822900093
248
BEARING BRACKET
251
NUT GEARSHIFT LEVER KNOB TO GEARSHIFT LEVER
254
SPRING RETAINER SPRING TO PUSH ROD
254
SPRING RETAINER CLUTCH PEDAL RESET
257
SPRING CLUTCH PEDAL RESET,B 974884
257
SPRING CLUTCH PEDAL RESET,B 974885
260
SPRING RETAINER SPRING TO PUSH ROD
261
CLIP SPRING TO PUSH ROD
263
LOCK RING PUSH ROD TO PEDAL
266
WASHER BRACKET TO FENDER BRACKET
999
WASHER PLUG SOCKET TO BRACKET
999
SPRING WASHER BRAKE SHOE WITH LINING
