Поз.
Артикул
Описание
5
8
CROSS MEMBER , Replaced By: A6883107222
8
CROSS MEMBER , Replaced By: A3883107222
11
11
COUPLING PIN ,B 981820
14
LOCKING SPRING TOP,B 981820
17
LOCKING SPRING BOTTOM
20
REAR SUBFRAME (FRONT SPRING BRACKET),FRONT
23
SCREW ENGINE SUPPORT TO SIDE MEMBERS M 12X40
26
NUT , Replaced By: N910113012003
29
REAR SUBFRAME , Replaced By: A6883207070
32
CROSS MEMBERNO.2,D 012825
35
SCREW BRACKET TO FRAME M 10X28
35
SCREW HAND PUMP TO BRACKET
35
SCREW BRACKET TO BUMPER,LEFT M 10X25
38
NUT , Replaced By: N910113010000
41
CROSS MEMBERNO. 3
44
47
CROSS MEMBER
50
BRACKET
53
BRACKET
56
SPRING BRACKET (REAR SPRING BRACKET),FRONT
59
CROSS MEMBER SHOCK ABSORBER NO.6
62
CROSS MEMBER SHOCK ABSORBER NO.7
65
CONSOLE , Replaced By: A6883117063
68
BRACKET HELPER SPRING
68
BRACKET HELPER SPRING
71
SPRING BRACKET (REAR SPRING BRACKET),REAR M18X1,5 MM
74
CROSS MEMBER825 MM
77
RIVET14X55 MM, TO BE ADAPTED DURING ASSEMBLY
77
77
RIVET BEARING BRACKET TO SIDE MEMBER, TO BE ADAPTED DURING ASSEMBLY
77
RIVET REFLECTOR TO BRACKET
77
RIVET14X48 MM
77
RIVET12X46 MM
77
RIVET REINFORCEMENT TO SIDE MEMBER
77
RIVET10X34 MM, TO BE ADAPTED DURING ASSEMBLY
77
RIVET GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS 10X26 MM
77
RIVET14X40 MM
77
RIVET CONSOLE TO SIDE MEMBER 10X26 MM
80
83
SCREW BRACKET TO BUMPER,LEFT M 10X25
86
WASHER GROUND CABLE
999
CROSS MEMBER PROPELLER SHAFT BEARING NO.4,B 984609
