Поз.
Артикул
Описание
182
HOSE FEED AND RETURN LINE CONNECTION, LENGTH AVAILABLE 1000 MM
188
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
188
HOSE , Replaced By: N900271015037
191
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
194
CLAMP HOSE 70-90X13 MM
194
CLAMP , Replaced By: N000000000672
194
CLAMP , Replaced By: N000000000674
194
CLAMP HOSE FASTENING 50-70X13 MM
200
CLAMP HOSE TO FITTING AND TO OIL TANK
200
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
218
HOSE
218
HOSE RETURN, TO BE ADAPTED DURING ASSEMBLY
221
COOLING WATER PIPE FROM THERMOSTAT TO CONNECTING HOSE
221
COOLING WATER PIPE CONNECTION OF COOLING WATER LINES
224
SCREW PLUG 3/2-WAY VALVE,CONNECTION:,5 363121
227
SEAL RING LINE CONNECTION
230
RUBBER BUFFER COVERING TO FRAME
233
PAD FEED LINE TO BRACKET
236
SCREW PIPE CLAMP
236
SCREW BRACKET TO CROSS CONNECTION STRUT
236
SCREW , Replaced By: N304017008021
236
SCREW , Replaced By: N304017008034
239
CLAMP FEED LINE TO BRACKET
242
CLAMP LINE MOUNTING
245
WASHER EXHAUST MUFFLER TO STRAP
248
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
248
NUT , Replaced By: N913004008001
301
OUTLET FEED, OIL COOLER
304
GASKET OUTLET TO ENGINE
307
HEXAGON HEAD BOLT CLAMP TO EXHAUST PIPE
307
SCREW BRACKET TO SIDE MEMBER
307
SCREW , Replaced By: N304014010004
307
SCREW , Replaced By: N304017010002
310
SPRING WASHER STEERING COLUMN BRACKET TO CAB
313
LINE COOLING WATER FEED TOWARD OIL COOLER
319
HOSE FEED AND RETURN LINE CONNECTION, LENGTH AVAILABLE 1000 MM
334
COOLING WATER PIPE FROM OIL COOLER TO RETURN HOSE CONNECTION
337
CLAMP HOSE FASTENING 50-70X13 MM
337
CLAMP , Replaced By: N000000000672
340
HOSE RETURN, TO BE ADAPTED DURING ASSEMBLY
343
BRACKET COOLING WATER LINE TO BRACKET
352
LINE FROM OIL COOLER TO RETURN HOSE CONNECTION
358
GASKET
361
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
361
SCREW , Replaced By: N304017008027
364
SPRING WASHER , Replaced By: N000137008212
364
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
367
BRACKET COOLING WATER LINE TO ENGINE,076058
370
BRACKET LINES TO BRACKET
373
CLAMP LINE MOUNTING
373
CLAMP , Replaced By: N071555050503
373
CLAMP , Replaced By: A9424310043
373
CLAMP , Replaced By: N000000001641
373
CLAMP FEED LINE TO BRACKET
376
CLAMP SUCTION LINE TO CROSS MEMBER
379
CLAMP LINE MOUNTING
379
CLAMP , Replaced By: A9424310043
379
CLAMP , Replaced By: N000000001641
382
SCREW CAB FLOOR COVERING M 6X25
385
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
385
SCREW , Replaced By: N304017008027
388
WASHER EXHAUST MUFFLER TO STRAP
391
WASHER COMPRESSED AIR LINE TO BRACKET
391
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
394
NUT , Replaced By: N913004008001
394
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
397
NUT PUMP TO BRACKET
400
PAD FEED LINE TO BRACKET
999
SEALING TAPE. ADHESIVE TAPE AIR INTAKE PIPE TO BRACKET
999
CHECK VALVE
