Поз.
Артикул
Описание
74
TEST CONNECTION
74
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
74
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
74
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
74
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
77
PLUG
80
FITTING FROM 3/2-WAY VALVE TO PRESSURE CONTROL VALVE
83
ADAPTER FITTING TEST CONNECTION
86
ADAPTER FITTING FLUID RESERVOIR TO BRACKET
89
FITTING QUICK BREATHER VALVE,REAR, CONNECTION: "23"
92
FITTING TEST CONNECTIONS
95
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
98
TEST CONNECTION
101
SCREW. UNION SCREW LINE CONNECTION
101
SCREW. UNION SCREW , Replaced By: A0009973734
104
BRACKET TEST CONNECTION
107
SCREW PUMP TO BRACKET
107
SCREW , Replaced By: N304017006016
110
NUT , Replaced By: N913004006001
110
NUT PUMP TO BRACKET
113
FITTING AT BRACKET
116
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
122
COUPLING MUFFLER TO SUBSTRUCTURE
125
WASHER COILED TUBE TO BRAKE LINE COUPLING SUPPORT
128
NUT BRACKET TO SIDE MEMBER
131
SCREW. UNION SCREW LINE CONNECTION
134
T-FITTING EXHAUST-BRAKE POWER CYLINDER
137
WASHER
140
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
999
BRACKET MOUNTING USED FOR COMPRESSED AIR LINES, NOT USED
