Поз.
Артикул
Описание
5
LINE FROM FOUR-CIRCUIT PROTECTIVE VALVE TO AIR RESERVOIR 9X12 MM, LENGTH AVAILABLE 3000 MM
5
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
5
HOSE , Replaced By: A0009872827
8
FITTING (PARTS KIT),LINE RUPTURE
9
CONNECTOR REPAIR SIZE
11
UNION NUT LINE CONNECTION, Replaced By: N000000006239
14
GLAND , Replaced By: A0019901967
17
SLEEVE LINE CONNECTION
20
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
35
FITTING DELIVERY LINE TO FRAME
38
NUT BRACKET TO SIDE MEMBER
41
T-FITTING RELAY VALVE,CONNECTION: "20"
41
T-FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "10"
44
FITTING RELAY VALVE,CONNECTION: "10",950459
47
FITTING TWO-WAY VALVE,CONNECTIONS: "1","2"
47
ELBOW FITTING DELIVERY LINE TO PUMP
53
FITTING BETWEEN THE LINES
56
FITTING DELIVERY LINE TO PUMP
59
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
62
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
