Поз.
Артикул
Описание
224
HOUSING OIL COOLER
224
HOUSING , Replaced By: A0002710301
227
GASKET , Replaced By: A0002712480
227
GASKET , Replaced By: A0002713480
227
GASKET CASE TO TRANSMISSION CASE
230
WASHER BRACKET TO CROSS MEMBER
233
HEXALOBULAR BOLT. SCREWM 8X45
233
SCREW , Replaced By: N000000001448
236
SEAL RING PNEUMATIC VALVE
239
SCREW PLUG, FILLING HOUSING,BOTTOM
239
SCREW PLUG , Replaced By: N000000000648
242
SEALING RING. SEAL RING ENGINE BREATHING
245
SCREW PLUGTO 000 553 03 05,000 553 18 05,
245
SCREW PLUG , Replaced By: N000908014009
248
RESERVOIR , Replaced By: A0002700446
248
RESERVOIR , Replaced By: A0002700546
248
RESERVOIR RETARDER ACCUMULATOR
251
COVER
254
COVER
257
PIPE
257
PIPE , Replaced By: A0002712696
260
PISTON
263
SEAL RING
266
SEAL RING , Replaced By: A0199975947
266
SEAL RING
269
PISTON GUIDE
272
STUD
275
WASHER , Replaced By: N000125008443
275
WASHER EXHAUST MUFFLER TO STRAP
278
NUT , Replaced By: N913004008004
278
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
278
NUT , Replaced By: N913004008001
278
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
281
SEAL RING RESERVOIR TO OIL COOLER HOUSING
284
WASHER
287
SCREW , Replaced By: N000000001448
287
HEXALOBULAR BOLT. SCREWM 8X45
290
VALVE (SOLENOID VALVE)
293
SEAL RING LINE CONNECTION
296
SCREW PLUGM 12X1.5
299
SEAL RING SOLENOID VALVE TO OIL COOLER HOUSING
302
WASHER EXHAUST MUFFLER TO STRAP
302
WASHER , Replaced By: N000125008443
305
SCREW , Replaced By: N304017008043
305
SCREW VALVE TO BRACKET M 8X55
308
COVERING RETARDER ACCUMULATOR
308
BRACKET , Replaced By: A0002710388
311
SPACER WASHER , Replaced By: A0002710152, +001A0002710352
311
SPACER WASHER BRACKET TO RETARDER ACCUMULATOR 0.60 MM
311
SPACER WASHER RETARDER ACCUMULATOR 2.00 MM
311
SPACER WASHER , Replaced By: A4602840552
311
SPACER WASHER , Replaced By: A4602840352
311
SPACER WASHER , Replaced By: A4602840352
311
SPACER WASHER , Replaced By: A4602840352
311
SPACER WASHER , Replaced By: A4602840352
314
WASHER , Replaced By: A4602840352
314
WASHER , Replaced By: A4602840352
314
WASHER , Replaced By: A4602840352
314
WASHER BRACKET TO RETARDER ACCUMULATOR 1.20 MM
314
SPACER WASHER BRACKET TO RETARDER ACCUMULATOR 0.60 MM
314
WASHER BRACKET TO RETARDER ACCUMULATOR 0.80 MM
314
WASHER BRACKET TO RETARDER ACCUMULATOR 0.60 MM
317
WASHER EXHAUST MUFFLER TO STRAP
317
WASHER , Replaced By: N000125008443
320
SCREW , Replaced By: N304017008034
320
SCREW BRACKET TO CROSS CONNECTION STRUT
323
NUT INTERMEDIATE SPEED STOP
326
SEAL RING OIL LINE
326
SEAL RING , Replaced By: A0209970948
329
PIPE OIL COOLER,TOP AND BOTTOM
