Поз.
Артикул
Описание
5
VALVE (CONTROL VALVE)
5
VALVE , Replaced By: A0012600757
5
VALVE , Replaced By: A0012601457
5
VALVE , Replaced By: A0012608557
5
VALVE , Replaced By: A0012608557
8
SEAL RING VALVE
11
PISTON CONTROL VALVE
14
COVER CONTROL VALVE
17
GASKET TRANSMISSION CASE
20
SCREW VALVE TO TRANSMISSION
23
LOCK WASHER TOP COVER TO SHIFT CASE, L.H.D., FROM TRANSMISSION N 047285, R.H.D.:FROM TRANSMISSION N 042437 (MANUFACTURED IN FRANCE)
26
GUIDE SLEEVE SHIFTING SHAFT
29
PRESSURE SPRING SHIFTING FORK
32
DETENT CONTROL VALVE
35
REPAIR KIT CONTROL VALVE
38
BREATHER CONTROL VALVE
41
VALVE (CONTROL VALVE)
41
VALVE , Replaced By: A0012600857
41
VALVE , Replaced By: A0012607257
44
GASKET SIDE COVER TO SHIFT CASE
47
SCREW SIDE COVER TO SHIFT CASE
50
BREATHER TRANSMISSION
56
SWITCH NEUTRAL POSITION SWITCH
59
AIR CLEANER CONTROL VALVE
62
REPAIR KIT AIR CLEANER
65
CLAMP AIR CLEANER
68
LOCK WASHER TOP COVER TO SHIFT CASE, L.H.D., FROM TRANSMISSION N 047285, R.H.D.:FROM TRANSMISSION N 042437 (MANUFACTURED IN FRANCE)
71
NUT BRACKET TO BRACKET
74
BRACKET AT TRANSMISSION CASE REAR COVER
77
SCREW BRACKET TO COMPRESSOR, TO BE ADAPTED DURING ASSEMBLY
80
FITTING AIR CLEANER
83
PRESSURE REGULATOR TRANSMISSION
86
FITTING AIR COMPRESSOR CONNECTION
89
ELBOW FITTING CONTROL VALVE
92
THREADED UNION CONTROL VALVE
95
T-FITTING 4/2-WAY VALVE
98
FITTING CONTROL VALVE
101
SCREW CLUTCH BRAKE
104
ELBOW FITTING CONNECTION TO NEUTRAL POSITION CYLINDER TO 000 260 38 05
107
SEAL RING SCREW FITTING
107
SEAL RING , Replaced By: A0079973048
110
ELBOW FITTING CONTROL VALVE
113
FITTING , Replaced By: A0029908568
113
FITTING LINE MOUNTING
116
T-FITTING 4/2-WAY VALVE
119
NIPPLE 4/2-WAY VALVE
122
ELBOW FITTING , Replaced By: A0019905171
122
ELBOW FITTING 3/2-WAY VALVE
125
ELBOW FITTING SHIFTING CYLINDER COVER
137
HOSE SHIFT LEVER VALVE,SPLITTER CYLINDER, CONTROL VALVE 1120 MM,5 091743
137
LINE , Replaced By: A3469971382
137
LINE , Replaced By: A3469971382
137
LINE , Replaced By: A3469971382
140
NUT , Replaced By: A0029908568
140
FITTING LINE MOUNTING
143
SEAL CONE LINE MOUNTING
146
LINE , Replaced By: A0002670849
146
LINE FAST GROUP
149
LINE FAST GROUP
152
LINE SLOW GROUP
161
CLAMP LINE TO BRACKET
999
REPAIR KIT CONTROL VALVE TO 001 260 85 57
