Поз.
Артикул
Описание
5
BRAKE VALVE TWO-CIRCUIT BRAKE WABCO
8
RS BRAKE VALVE REPAIR KIT, AB VENTIL-FERTIGUNG KW 21/01 (SIEHE TYPSCHILD BREMSVENTIL)
8
RS BRAKE VALVE , BIS VENTIL-FERTIGUNG KW 20/01 (SIEHE TYPSCHILD BREMSVENTIL)
11
SCREW BRAKE VALVE TO SUBSTRUCTURE M 8 X 35
14
MUFFLER VALVE BLEEDING
14
MUFFLER BRAKE VALVE
17
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
20
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
23
SCREW. UNION SCREW LINE CONNECTION
26
LOOM TIE365 MM
29
VALVE FRONT AXLE II RELAY VALVE "WABCO"
29
VALVE FRONT AXLE II RELAY VALVE "GRAU", NOT USED
29
VALVE FRONT AXLE II RELAY VALVE "BOSCH"
32
REPAIR KIT RELAY VALVE TO 004 429 38 44,WABCO
32
REPAIR KIT RELAY VALVE BOSCH
32
REPAIR KIT RELAY VALVE "GRAU"
35
FITTING FRONT-AXLE/REAR-AXLE REGULATING SOLENOID VALVE,CONNECTIONS: "20,21,22"
38
FITTING SHUTTLE VALVE,CONNECTIONS: "2,11,12"
41
O-RING CHECK VALVE TO AIR RESERVOIR
44
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
47
NUT CHECK VALVE TO AIR RESERVOIR
50
T-FITTING BRAKE POWER REGULATOR,CONNECTION: "10", Replaced By: A0049971689, +001A0009974834
50
T-FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "21,22"
53
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
53
THRUST RING CHECK VALVE TO AIR RESERVOIR
53
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
56
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
59
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
62
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
62
SEAL RING , Replaced By: A0009940747
65
LOCK , Replaced By: A0009945448
65
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
68
SCREW. UNION SCREW , Replaced By: A0009973734
68
SCREW. UNION SCREW LINE CONNECTION
71
MUFFLER VALVE BLEEDING
71
MUFFLER BRAKE VALVE
74
VALVE FRONT AXLE SELF-LEVELLING DEVICE
77
PROTECTIVE CAPWABCO
80
MAGNET ,5 760168K 154651
83
REPAIR KIT AIR SPRING VALVE
86
T-FITTING BRAKE POWER REGULATOR,CONNECTION: "10", Replaced By: A0049971689, +001A0009974834
89
SEAL RING , Replaced By: A0009940747
89
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
92
LOCK , Replaced By: A0009945448
92
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
95
SCREW. UNION SCREW , Replaced By: A0009973734
95
SCREW. UNION SCREW LINE CONNECTION
98
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL
98
SCREW VALVE TO BRACKET M 8X55
101
NUT POWER CYLINDER TO SPRING SUPPORT
101
NUT HORN TO BRACKET M8
104
NON-RETURN VALVE. VALVE WITH CHECK VALVE WABCO,5 433388
107
VALVE SEAT RINGWABCO,5 433388
110
BUSHINGWABCO,5 433388
111
LOCK RINGWABCO,5 433388
112
REPAIR KITWABCO
116
FITTING AIR RESERVOIR
116
FITTING AT AIR RESERVOIR
116
FITTING LINE CONNECTION
119
NUT CHECK VALVE TO AIR RESERVOIR
122
T-FITTING BRAKE POWER REGULATOR,CONNECTION: "10", Replaced By: A0049971689, +001A0009974834
125
WASHER
128
FITTING LINE CONNECTION
128
FITTING CHECK VALVE
131
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
131
THRUST RING CHECK VALVE TO AIR RESERVOIR
134
O-RING CHECK VALVE TO AIR RESERVOIR
137
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
140
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
143
SCREW. UNION SCREW LINE CONNECTION
