Поз.
Артикул
Описание
5
GEAR SET DRIVE SHAFT,186631
5
GEAR SET ,186630, Replaced By: A0002601897, +001A0002622934
8
SPACER WASHER , Replaced By: A0012623152
8
SPACER WASHER , Replaced By: A0012623352
8
SPACER WASHER , Replaced By: A0012623652
8
SPACER WASHER DRIVE SHAFT,AS REQUIRED 1.00 MM
8
SPACER WASHER DRIVE SHAFT,AS REQUIRED 1.30 MM
8
SPACER WASHER DRIVE SHAFT,AS REQUIRED 1.50 MM
11
GROOVED BALL BEARING FRONT DRIVE SHAFT
11
BALL BEARING , Replaced By: N000625506306
14
SNAP RING
17
SPACER WASHER AS REQUIRED 0.70 MM
17
SPACER WASHER AS REQUIRED 1.00 MM
20
MAIN SHAFT
23
NEEDLE BEARING 1ST SPEED
29
SYNCHRONIZER RING 1ST THRU 4TH SPEED
29
SYNCHRONIZER RING , Replaced By: A0002622934
32
SLIDING COLLAR 3RD AND 4TH SPEED
35
SYNCHRONIZER BODY 3RD AND 4TH SPEED
38
RETAINING RING 1ST THRU 4TH SPEED
38
RETAINING RING , Replaced By: A0002620739
41
FOLLOWER 1ST THRU 4TH SPEED
44
LOCK MAINSHAFT, AS REQUIRED 1.90 MM
44
LOCK GUIDE TUBE
44
LOCK MAINSHAFT, AS REQUIRED 1.80 MM
47
NEEDLE BEARING MAIN SHAFT,FRONT
50
NEEDLE BEARING 2ND SPEED
56
SLIDING COLLAR 1ST AND 2ND SPEED
59
SNAP RING 1ST AND 2ND SPEED 2.00 MM
62
NEEDLE BEARING 1ST SPEED
65
REVERSE IDLER GEAR
68
GROOVED BALL BEARING FRONT DRIVE SHAFT
68
BALL BEARING , Replaced By: N000625506306
71
SPACER WASHER MAINSHAFT, AS REQUIRED 0.80 MM
71
SPACER WASHER MAINSHAFT, AS REQUIRED 1.20 MM
74
SNAP RING
77
SPACER WASHER MAIN SHAFT,REAR
80
SEAL RING MAIN SHAFT,REAR
80
SEAL RING , Replaced By: A0159979747
83
LOCK FLANGE TO MAIN SHAFT
86
SNAP RING FLANGE TO MAIN SHAFT
89
FLANGE MAIN SHAFT OUTPUT
92
LOCK RING DRIVE GEAR
95
TAPERED ROLLER BEARING FRONT
98
SPACER WASHER COUNTERSHAFT,AS REQUIRED 1.75 MM
98
SPACER WASHER COUNTERSHAFT,AS REQUIRED 0.75 MM
98
SPACER WASHER COUNTERSHAFT,AS REQUIRED 1.95 MM
98
SPACER WASHER COUNTERSHAFT,AS REQUIRED 0.60 MM
98
SPACER WASHER COUNTERSHAFT,AS REQUIRED 1.05 MM
98
SPACER WASHER COUNTERSHAFT,AS REQUIRED 1.55 MM
98
SPACER WASHER COUNTERSHAFT,AS REQUIRED 1.65 MM
98
SPACER WASHER , Replaced By: A0012627052
98
SPACER WASHER , Replaced By: A0012625952
98
SPACER WASHER , Replaced By: A0012626852
98
SPACER WASHER , Replaced By: A0012626552
98
SPACER WASHER , Replaced By: A0012627252
98
SPACER WASHER , Replaced By: A0012627452
98
SPACER WASHER , Replaced By: A0012627652
101
LOCK RING P.T.O.
104
REVERSE IDLER SHAFT
107
REVERSE IDLER GEAR
999
SYNCHRONIZER BODY 1ST AND 2ND SPEED
