Главная
›
Mercedes
›
BUS
›
O350 TOURISMO-RHD O 403-RHD EURO2
›
613.455
›
42 BRAKES
›
380 SERVICE BRAKE VALVE,RELAY VALVE, TWO-WAY VALVE IL. 2
Mercedes N304017008021 - АВТОЗАПЧАСТЬ
O350 TOURISMO-RHD O 403-RHD EURO2 613.455
42 BRAKES - 380 SERVICE BRAKE VALVE,RELAY VALVE, TWO-WAY VALVE IL. 2
Поз.
Артикул
Описание
17
A0045424620
HORN24 V
17
A6135420020
HORN
20
A0005422921
AIR HORN
20
A0005422821
AIR HORN
21
A6135420121
AIR HORN
22
A6134270041
BRACKET AIR HORN
23
A0009970834
SCREW. UNION SCREW , Replaced By: A0009973734
26
A0009941248
LOCK , Replaced By: A0009945448
29
A0009940047
SEAL RING , Replaced By: A0009940747
30
N003861008005
GLAND LINE CONNECTION
31
N915017008100
UNION NUT LINE CONNECTION
32
N915062006000
SLEEVE LINE CONNECTION
33
A6134200058
BRAKE LINE COUPLING AIR HORN CONNECTION
34
N304017008021
SCREW PIPE CLAMP
34
N910105008026
SCREW BRACKET TO CAB REAR PANEL M 8X20
35
A0039907612
SCREWM4X8
35
N000084004434
SCREW ELECTRIC CABLE TO HORN
38
A0039907612
SCREWM4X8
38
N007985010114
SCREW ROCKER PANEL TO STEP
41
N000125008417
WASHER TRAILER PLUG SOCKET TO BRACKET
41
N000125008445
WASHER PUMP TO CONSOLE
44
N304032010003
NUT BATTERY CABLE
44
N910112010001
NUT , Replaced By: N913023010002
47
N913023008003
NUT HORN TO BRACKET M8
