Поз.
Артикул
Описание
5
P.T.O.
8
CASE , 714.2 8-SPEED,FROM TRANSMISSION 022106,9-SPEED,FROM TRANSMISSION 007289,714.3 FROM TRANSMISSION 004580
11
GASKET , Replaced By: A3852642580
11
GASKET P.T.O. TO TRANSMISSION
14
FITTED WASHER
17
NEEDLE BEARING DRIVE SHAFT
20
GEAR DRIVE
23
SLIDING COLLAR
26
ROLLER ASSEMBLY
26
ROLLER ASSEMBLY , Replaced By: A0029813412
26
ROLLER ASSEMBLY
26
ROLLER ASSEMBLY
26
ROLLER ASSEMBLY
26
ROLLER ASSEMBLY
29
RING , 714.2 8-SPEED,FROM TRANSMISSION 022106,9-SPEED,FROM TRANSMISSION 007289,714.3 FROM TRANSMISSION 004580
32
CLAMPING SLEEVE
35
SNAP RING
38
BALL BEARING
38
BALL BEARING
41
LOCK RING DRIVE GEAR
44
INTERMEDIATE SHAFT
47
SHAFT (SHIFTING SHAFT), 714.2 8-SPEED,FROM TRANSMISSION 022106,9-SPEED,FROM TRANSMISSION 007289,714.3 FROM TRANSMISSION 004580
50
SLIDE SHIFTING FORK
53
SHIFTING FORK P.T.O., 714.2 8-SPEED,FROM TRANSMISSION 022106,9-SPEED,FROM TRANSMISSION 007289,714.3 FROM TRANSMISSION 004580
56
CLAMPING SLEEVE CRANK TO BUSHING
59
SEAL RING
62
SCREW P.T.O. TO TRANSMISSION M10X50
62
SCREW P.T.O. TO TRANSMISSION M10X85
62
SCREW P.T.O. TO TRANSMISSION M10X75
65
LOCK PLATE P.T.O. TO TRANSMISSION
68
SPRING WASHER STEERING COLUMN BRACKET TO CAB
71
STUD P.T.O. HOUSING
74
NUT COVER TO FLANGE
77
DRIVE SHAFT
80
NEEDLE BEARING DRIVE SHAFT
86
BALL BEARING DRIVE SHAFT,183596
86
BALL BEARING DRIVE SHAFT,183596
86
BALL BEARING , Replaced By: A0089814225
89
SNAP RING DRIVE SHAFT
92
SEAL RING
95
COVER
98
GASKET , Replaced By: A3852641680
98
GASKET , Replaced By: A6022640280
101
COUPLING FLANGE
104
WASHER FLANGE TO SHAFT
107
SCREW FLANGE TO SHAFT
110
SPRING WASHER CAB FLOOR
113
NUT COVER TO FLANGE
116
SHIFTING CYLINDER P.T.O.
119
BUSHING
122
GROOVED RING
125
SEALING CORD
128
PROTECTIVE CAP
131
YOKE OPERATING ROD,K 202311
134
PIN
137
SWITCH , Replaced By: A0005459009
140
PIN SHIFTING CYLINDER TO TRANSMISSION CASE
143
WASHER , Replaced By: N000125010532
146
NUT BRACKET TO TELESCOPIC TUBE,K 142858
149
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
152
UNIT IDENTIFICATION PLATE P.T.O.
155
GROOVED NAIL3X4,TO 000 431 94 14,000 431 96 14
