Поз.
Артикул
Описание
3
VALVE 5/2-WAY
3
VALVE 5/2-WAY PW A 001 260 26 57
6
REPAIR KIT 5/2-WAY VALVE TO 001 260 26 57
9
PIN VALVE TO SHIFT CASE
12
SCREW TWO-WAY VALVE TO CONTROL VALVE,4 719029
15
SPRING WASHER ALTERNATOR CONNECTION D+
21
PIN DECLUTCHING START SWITCH
24
COVER , Replaced By: A3872612033
24
COVER BACK-UP LIGHT SWITCH
30
SWITCH , Replaced By: A0005459009
33
GASKET , Replaced By: A3852613680
36
SCREW , Replaced By: N304017008021
36
SCREW PIPE CLAMP
39
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
42
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
45
UNION NUT
48
SEAL CONE
48
GLAND , Replaced By: A0019901667
51
SLEEVE LEAK LINE
54
SLEEVE LINE CONNECTION
57
FITTING 3/2-WAY VALVE,CONNECTION: "30"
57
FITTING , Replaced By: A0039972172
57
FITTINGTO 003 131 59 01
60
SEAL RING , Replaced By: N007603010110
63
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
