Поз.
Артикул
Описание
5
TRANSMISSION CASE FRONT PART
14
TRANSMISSION CASE COVER FRONT DRIVE SHAFT,050225
17
SPACER WASHER , Replaced By: A3872620252
17
SPACER WASHER , Replaced By: A3872620252
17
SPACER WASHER , Replaced By: A3872620452
17
SPACER WASHER , Replaced By: A3872620452
17
SPACER WASHER DRIVE SHAFT,AS REQUIRED 1.45 MM
17
SPACER WASHER , Replaced By: A3872621152
17
SPACER WASHER OUTPUT SHAFT,AS REQUIRED 1.10 MM
17
SPACER WASHER MAINSHAFT, AS REQUIRED 1.20 MM
17
SPACER WASHER DRIVE SHAFT,AS REQUIRED 1.30 MM
17
SPACER WASHER OUTPUT SHAFT,AS REQUIRED 1.50 MM
20
GASKET CASE COVER
20
GASKET , Replaced By: A3872614480
23
SEAL RING
23
SEAL RING CASE COVER
23
SEAL RING CASE COVER
29
SCREW CYLINDER TO TRANSMISSION CASE
32
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
32
SPRING WASHER , Replaced By: N000137008212
47
CAP ,050224, Replaced By: A3872610382, +001A3872612218
47
CAP
50
COVER TRANSMISSION CASE FRONT PART
50
COVER , Replaced By: A3892610633
50
COVER
50
COVER , Replaced By: A3892611933, +006N914146010108
53
SPACER WASHER AS REQUIRED 0.10 MM
53
SPACER WASHER AS REQUIRED 0.20 MM
53
SPACER WASHER , Replaced By: A4063370352
53
SPACER WASHER AS REQUIRED 0.05 MM
53
SPACER WASHER , Replaced By: A4063370552
53
SPACER WASHER AS REQUIRED 0.10 MM, UP TO IDENT NO. 4 477510 FROM IDENT NO. SEE UNIT MICROFICHE,MODEL 750.5
53
SPACER WASHER COUNTERSHAFT,AS REQUIRED 1.00 MM,375914
53
SPACER WASHER AS REQUIRED 0.40 MM
53
SPACER WASHER COUNTERSHAFT,AS REQUIRED 2.00 MM,375914
53
SPACER WASHER COUNTERSHAFT,AS REQUIRED 0.15 MM
53
SPACER WASHER COUNTERSHAFT,AS REQUIRED 0.50 MM
53
SPACER WASHER COUNTERSHAFT,AS REQUIRED 3.00 MM,375914
56
GASKET COVER TO TRANSMISSION CASE FRONT PART
56
GASKET , Replaced By: A3872614580
59
SCREW COVER TO TRANSMISSION M10X22
62
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
65
TRANSMISSION CASE REAR
65
TRANSMISSION CASE REAR,714.620 , 086595 714.640 , 088677714.620 , 086595 714.640 , 088677
65
TRANSMISSION CASE , Replaced By: A3872615003
65
TRANSMISSION CASE , Replaced By: A3872614703, +001A3859970130
68
SCREW PLUG TRANSMISSION CASE TOP COVER
71
PIN COVER TO P.T.O. CASE
71
CYLINDRICAL PIN , Replaced By: A3879970110
73
SCREW P.T.O. TO TRANSMISSION M 10X60
75
SCREW TRANSMISSION CASE FRONT PART TO REAR PART M 10X60
77
SPRING WASHER STEERING COLUMN BRACKET TO CAB
78
UNIT IDENTIFICATION PLATE TRANSMISSION CASE
79
RIVET UNIT IDENTIFICATION PLATE TO TRANSMISSION CASE
79
GROOVED NAIL
80
SCREW PLUG , Replaced By: A0009972632
83
SCREW PLUG HOUSING,BOTTOM,183596
83
SCREW PLUG HOUSING,BOTTOM,183596
84
PLUG
