Поз.
Артикул
Описание
125
SENDER UNIT WATER TEMPERATURE GAUGE
125
SENDER UNIT WATER TEMPERATURE GAUGE
128
SEAL RING
143
THERMOSTAT
149
THERMOSTAT 80 DEGREES,RANGE OF DELIVERY, 912 10/50,20/60 073576 912 12/52,22/62 067786
167
COVER , 912 10/50,20/60 073576 912 12/52,22/62 067786 MITLIEFERN:3 SCHRAUBEN 914005006008 AB MOTOR 912 10/50,20/60 213449 912 12/52,22/62 163443
188
GASKET
191
COMBINATION BOLT , Replaced By: N000933006123, +001N000137006204
191
SCREW OIL LINE TO CRANKCASE
194
SCREW PLUG , Replaced By: N007604014110
194
SCREW PLUG FUEL TANK
197
SEAL RING FUEL LINE TO FEED PUMP
209
HOSE FROM THERMOSTAT TO RADIATOR FILLER NECK, ORDER BY THE METER
212
CLAMP , Replaced By: A0069970690
212
LOOM TIE. CLAMP BRAKE HOSE 45-55 MM, DISCONTINUED,PART IS NO LONGER REQUIRED
218
GASKET THERMOSTAT TO CYLINDER HEAD
218
GASKET , Replaced By: A6162030280
224
SCREW VALVE TO BRACKET, Replaced By: N304014008002
224
SCREW VALVE TO BRACKET
230
SPRING WASHER , Replaced By: N000137008212
230
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
