Поз.
Артикул
Описание
5
SCREW BRACKET TO TRANSMISSION CASE
8
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
8
SPRING WASHER CAB FLOOR
20
GASKET , Replaced By: A1021510180
20
GASKET STARTING MOTOR TO CRANKCASE
26
ANGLE
35
SCREW COVER PLATE TO BRACKET
38
SPRING WASHER CAB FLOOR
38
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
41
WASHER COMPRESSED AIR LINE TO BRACKET
41
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
80
COVER (AIR INTAKE COVER)
83
SPRING WASHER ALTERNATOR CONNECTION D+
86
NUT TACHOGRAPH TO BRACKET
89
HOSE AIR INTAKE COVER TO ALTERNATOR
92
CLAMP , Replaced By: A0069972790
92
LOOM TIE LINE MOUNTING
116
SUPPORT ALTERNATOR
122
SCREW STRUT TO CROSS MEMBER M 10X25
122
SCREW , Replaced By: N304017010040
134
SPRING WASHER STEERING COLUMN BRACKET TO CAB
158
SCREW BRACKET TO REAR AXLE
164
SPRING WASHER STEERING COLUMN BRACKET TO CAB
182
BRACKET ALTERNATOR READJUSTMENT
182
BRACKET , Replaced By: A6171500873
197
NUT , 912 10/50,20/60 073576 912 12/52,22/62 067786 919 000145
206
CLAMPING BOLT ALTERNATOR READJUSTMENT
212
SPACER TUBE , 912 10/50,20/60 073576 912 12/52,22/62 067786 919 000145
221
WASHER BRACKET TO COVERING
221
WASHER , Replaced By: N009021010209
227
NUT , Replaced By: N304032010002
227
NUT
239
SCREW BRACKET TO REAR AXLE
