Поз.
Артикул
Описание
5
SHIFTING ROD TRANSMISSION CASE,TOP
5
SHIFTING ROD TRANSMISSION CASE,TOP
14
PAWL , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO TRANSMISSION 001807, Replaced By: A3872680716, +001A3872680239
14
PAWL , Replaced By: A3872680916
14
PAWL SHIFTING ROD
17
SHIFTING FINGER , Replaced By: A3872681033
17
SHIFTING FINGER , Replaced By: A3872681033
17
SHIFTING FINGER SHIFTING ROD
20
CLAMPING PIN SHIFTING FINGER TO SHIFTING ROD
21
GUIDE PIVOT TRANSMISSION CASE
21
GUIDE PIVOT TRANSMISSION CASE
21
GUIDE PIVOT TRANSMISSION CASE,001807
21
GUIDE PIVOT , Replaced By: A9452680139
21
GUIDE PIVOT , Replaced By: A9452680139
21
GUIDE PIVOT , Replaced By: A9472680039
22
SWITCH , Replaced By: A0005459009
22
SWITCH , Replaced By: A0015452709
22
SWITCH TORQUE REDUCER
22
SWITCH BACK-UP LIGHT SWITCH
23
PIN DECLUTCHING START SWITCH
24
COVER BACK-UP LIGHT SWITCH
24
COVER , Replaced By: A3872612033
25
GASKET , Replaced By: A3852613680
25
GASKET 3/2-WAY VALVE
26
SCREW , Replaced By: N304017008021
26
SCREW PIPE CLAMP
27
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
28
SHIFTING TUBE TRANSMISSION CASE,TOP,109889
28
SHIFTING TUBE TRANSMISSION CASE,TOP,109889
28
SHIFTING TUBE ,109888, Replaced By: A3872607582, +001A3892680446, +002A3899970419
28
SHIFTING TUBE ,109888, Replaced By: A3872607682, +001A3892680446, +002A3899970419
29
GASKET BEARING COVER TO TRANSMISSION CASE
30
SCREW , Replaced By: N914126008078
30
SCREW BEARING BRACKET TO TRANSMISSION M 8X60,556500
31
SHIFTING SEGMENT ,108688, Replaced By: A3892680446, +001A3872605782, +002A3899970419
31
SHIFTING SEGMENT , Replaced By: A9452680013, +001A9452680474
31
SHIFTING SEGMENT SHIFTING TUBE
32
SPRING SHIFTING SEGMENT
35
SPRING SHIFTING SEGMENT
38
PIN GEAR INTERLOCK,128844
38
PIN SHIFTING SEGMENT
38
PIN , Replaced By: A9452680474, +001A9452680013
41
THREADED PIN , Replaced By: A3899970319
41
THREADED PIN , Replaced By: A3899970419
41
THREADED PIN , Replaced By: A3879970119
41
THREADED PIN SHIFTING SHAFT, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
41
THREADED PIN HOUSING REAR M10X16
44
WASHER SHIFTING ROD TO SHIFTING TUBE
47
SPRING SHIFTING TUBE, NORMAL GEARSHIFT SYSTEM
50
BUSHING SHIFTING TUBE
50
BUSHING , Replaced By: A3872680850
53
SNAP RING
56
SNAP RING
59
THRUST PIECE GEARSHIFT PATH SHIFT
59
THRUST PIECE AT SHIFTING ROD,048123
62
CLAMPING PIN THRUST PIECE TO SHIFTING ROD
65
EXPANSION PLUG EXHAUST FLAP BEARING
68
SHIFT CASE
68
SHIFT CASE , FIRST EXHAUST STOCK OF OLD PARTS UP TO TRANSMISSION 048123, Replaced By: A3892600272
68
SHIFT CASE , FIRST EXHAUST STOCK OF OLD PARTS UP TO TRANSMISSION 048123, Replaced By: A3892600372
68
SHIFT CASE
71
BUSHING SHIFT CASE
71
BUSHING SHIFT CASE
74
SHAFT (SHIFTING SHAFT),048123
74
SHAFT
74
SHAFT , Replaced By: A3892602238
74
SHAFT (SHIFTING SHAFT),048123
74
SHAFT
74
SHAFT (SHIFTING SHAFT)
80
CYLINDRICAL PIN SHIFTING SHAFT
83
WOODRUFF KEY BEARING BODY,6 900042
86
SELECTOR LEVER , Replaced By: A3892650230
86
SELECTOR LEVER (SELECTOR FINGER)
86
SELECTOR LEVER (SELECTOR FINGER),048123
89
SPACER WASHER SHIFTING SHAFT
92
SPACER WASHER SHIFTING SHAFT
95
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
98
SEAL RING SHIFT CASE, NORMAL GEARSHIFT SYSTEM
101
BUSHING SHIFT CASE, NORMAL GEARSHIFT SYSTEM
104
GASKET SHIFT CASE TO SHIFTING TUBE
104
GASKET , Replaced By: A3872681680
107
SCREW
107
SCREW CONTROL PLATE TO TRANSMISSION CASE M 8X65
