Поз.
Артикул
Описание
251
VALVE DOUBLE 3/2-WAY KNORR
257
GASKET VALVE TO BEARING COVER INTERLOCK
260
SCREW VALVE TO BEARING COVER INTERLOCK
263
SPRING WASHER , Replaced By: N000137008212
263
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
266
VALVE 5/2-WAY PW A 001 260 26 57
266
VALVE 5/2-WAY
269
REPAIR KIT 5/2-WAY VALVE TO 001 260 26 57
272
SCREW VALVE TO BRACKET
275
SPRING WASHER ALTERNATOR CONNECTION D+
302
PLASTIC PIPE AERATION, ORDER BY THE METER
302
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
305
FITTING (PARTS KIT),LINE RUPTURE
308
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
311
HOLLOW SCREW LINE MOUNTING,437171
311
HOLLOW SCREW CONTROLE CABLE AIR COMPRESSOR
314
SEAL RING SRREW PLUG
317
WASHER SOLENOID VALVE
320
INSULATING HOSE PROTECTION AGAINST SCORING 10 MM, SILIKON / SILICONE, ORDER BY THE METER
323
PLASTIC PIPE RISING PIPE 4X6 MM
323
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
326
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
329
LINE FROM 5/2-WAY VALVE TO ADDITIONAL GEARBOX CYLINDER, FAST GROUP "46/47"
329
LINE , Replaced By: A3892675149
329
LINE , Replaced By: A3892675149
332
LINE , Replaced By: A3892675249
332
LINE , MULTI-JOINT GEARSHIFT SYSTEM, Replaced By: A3892675249
332
LINE FROM 5/2-WAY VALVE TO ADDITIONAL GEARBOX CYLINDER, SLOW GROUP "46/47"
335
UNION NUT
338
SEAL CONE
338
GLAND , Replaced By: A0019901667
341
SLEEVE LINE CONNECTION
344
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
347
FITTINGTO 003 131 59 01
347
FITTING 3/2-WAY VALVE,CONNECTION: "30"
347
FITTING , Replaced By: A0039972172
350
HOLLOW SCREW LINE CONNECTION
353
SEAL RING LINE CONNECTION
353
SEAL RING PNEUMATIC VALVE
356
CONNECTOR
359
CONNECTOR
362
CONNECTOR COMPRESSED AIR LINE TO CLUTCH BOOSTER
365
SEAL RING CONNECTOR 11.8X2 MM
365
SEAL RING , Replaced By: A0229973948
368
SCREW CONNECTOR TO TRANSMISSION
374
BRACKET OIL LINE TO TRANSMISSION
377
SCREW BRACKET TO SIDE MEMBER
999
INSULATING HOSE FLEXIBLE, FOR CABLE HARNESS DIA.: 7.5 MM, ORDER BY THE METER
999
SWITCH , Replaced By: A0015455709
999
SWITCH
