Поз.
Артикул
Описание
5
POWER TAKE-OFFNA 121-2C, DETERMINE VARIANT NUMBER FROM VEDOC
5
P.T.O.NA 121-2B, DETERMINE VARIANT NUMBER FROM VEDOC
5
POWER TAKE-OFF , FOR COMPONENT PARTS SEE SPARE PARTS LIST
5
P.T.O. FOR BREAK-DOWN,SEE UNIT STANDARD VERSIONMODEL: 715.5 NA 121-1B
5
P.T.O. , Replaced By: XVV65040977
5
P.T.O. , Replaced By: XVV65040682
5
P.T.O. , Replaced By: XVV65040633
5
PART NAME MISSING , Replaced By: XVV65040306, +001A9452642327, +001A3812640780
5
P.T.O. , Replaced By: XVV65040617
5
P.T.O. , Replaced By: XVV65040318
5
P.T.O. , Replaced By: XVV65040319
5
P.T.O. , Replaced By: XVV65040317
5
P.T.O. , Replaced By: XVV65040318
5
P.T.O. , Replaced By: XVV65040306
5
POWER TAKE-OFF , DETERMINE VARIANT NUMBER FROM VEDOC
11
HOUSING P.T.O., Replaced By: A9452601126
11
HOUSING P.T.O.
11
HOUSING , FIRST EXHAUST STOCK OF OLD PARTS UP TO TRANSMISSION 341337, Replaced By: A9452641701
11
HOUSING , Replaced By: A9452642301
11
HOUSING P.T.O.
11
HOUSING P.T.O.
11
HOUSING P.T.O.
11
HOUSING P.T.O.
17
TYPE PLATE HOUSING,TOP
17
TYPE PLATE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A9455840301
20
GROOVED NAIL3X4,TO 000 431 94 14,000 431 96 14
23
THREADED PIN TRANSMISSION CASE TO TRANSMISSION CASE
26
SCREW PLUG TRANSMISSION CASE TO TRANSMISSION CASE
29
BUSHING P.T.O. HOUSING
32
STUD COVER TO P.T.O. CASE M12X60, TO A 945 264 03 11
32
STUD ATTACHMENT ON TRANSMISSION END
32
STUD COVER TO P.T.O. CASE M 12 X 54
32
STUD P.T.O. HOUSING M 12X67
32
SCREW COVER TO P.T.O. CASE M12X45
38
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
38
SPRING WASHER CAB FLOOR
41
NUT COVER TO FLANGE
44
GASKET P.T.O. TO TRANSMISSION
47
SCREW TRANSMISSION TO ENGINE M 10X40,K 269347
47
HEXAGON HEAD BOLT CONSOLE TO REAR CROSS MEMBER AND TO FRAME SIDE MEMBERS M 10X40
999
LINE TO P.T.O.
