Поз.
Артикул
Описание
9
PLASTIC PIPE RISING PIPE 4X6 MM
9
PLASTIC PIPE RISING PIPE 4X6 MM
9
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
17
UNION NUT
23
SEAL CONE
23
GLAND , Replaced By: A0019901667
29
SLEEVE LEAK LINE
35
BANJO UNION HOSE WIDTH, / I.D., 4/16 MM
41
FITTING LINE CONNECTION TO FIRE WALL,5 726664
41
FITTING , Replaced By: N915059004001
47
LOOM TIE LINE MOUNTING 280 MM
53
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
53
FITTING , Replaced By: A0019909871
59
TEST CONNECTION
59
TEST CONNECTION
65
WASHER
71
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
77
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
77
HOLLOW SCREW LINE TO OIL RADIATOR
83
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
89
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
95
FITTING TEST CONNECTION TO CAB, UP TO IDENT NO. 4 322431 AND FROM IDENT NO. 8 000001-8 001702
95
T-FITTING TEST CONNECTION
95
FITTING
101
T-FITTING EXHAUST-BRAKE POWER CYLINDER
107
UNION NUT
113
SEAL CONE
113
GLAND , Replaced By: A0019901667
119
SLEEVE LEAK LINE
125
BLOCK COMPRESSED AIR LINE MOUNTING,647876684145
131
PAD COMPRESSED AIR LINE MOUNTING,647876684145
137
PLATE TO SEAL CABLE HARNESS OPENING IN CAB
143
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING M 6X60
149
SCREW SWITCH TO BRACKET M6X35
149
SCREW , Replaced By: N007985006180
155
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
161
NUT BALL PIVOT TO LEVER
999
PROTECTIVE CAP COMPRESSED AIR LINE MOUNTING
999
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
999
LOCK WASHER FITTING TO BRACKET
