Поз.
Артикул
Описание
2
LEVER 5TH SPEED AND REVERSE
5
SPRING INTERLOCK OF 1ST THRU 4TH SPEED, 412 1 807064 413 1 809798
5
SPRING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A1249931015
11
BUSHING
14
PIN LEAF SPRING AND LOCKING LEVER TO TRANS MISSION CASE
17
WASHER
20
WASHER EXHAUST MUFFLER TO STRAP
20
WASHER , Replaced By: N000125008443
23
NUT , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: N000917008007, +001N000125008418
23
NUT
26
INTERLOCK CAGE
29
GASKETTO 123 260 05 73
32
SCREW , Replaced By: N304017006016
32
COMBINATION BOLT , Replaced By: N000933006130
32
SCREW PUMP TO BRACKET
35
SHIFTING FORK (SWINGING SHIFT LINK),3RD & 4TH SPEED
38
NEEDLE BEARING
38
NEEDLE BEARING
41
SHIFTING FORK 3RD AND 4TH SPEED
41
SHIFTING FORK 3RD AND 4TH SPEED, THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE
44
SHIFT LEVER 3RD AND 4TH SPEED
47
BUSHINGTO 201 260 12 39
51
SCREW GRIP RAIL MOUNTING M 8 X 35
51
SCREW SHIFT LEVER TO SWINGING SHIFT LINK
54
BUSHING LINE MOUNTING
54
SPACER TUBE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A1242670050, +001A1249900812
57
SEAL RING , Replaced By: A0269971348
57
SEAL RING DISC SUPPORT,000668
60
STOP SLEEVE
63
PIN SWINGING SHIFT LINK
63
SPINDLE , Replaced By: A1242650574
64
GASKET BEARING SPINDLE TO TRANSMISSION CASE
66
SEAL RING
68
SPRING WASHER LICENSE PLATE TO BRACKET
69
SCREW PUMP TO BRACKET
69
SCREW , Replaced By: N304017006016
71
SHIFTING FORK (SWINGING SHIFT LINK),1ST & 2ND SPEED
73
NEEDLE BEARING
73
NEEDLE BEARING
75
SHIFTING FORK 1ST AND 2ND SPEED, TYP 201
78
SHIFT LEVER 1ST AND 2ND SPEED,448 1 056684,449 1 066626
78
SHIFT LEVER ,448 1 056683,449 1 066625, Replaced By: A1242602639, +001A0009921010
81
BUSHING
81
BUSHINGTO 201 260 12 39
84
SCREW SHIFT LEVER TO SWINGING SHIFT LINK
87
BUSHING LINE MOUNTING
91
SEAL RING DISC SUPPORT,000668
91
SEAL RING , Replaced By: A0269971348
94
STOP SLEEVE
97
PIN SWINGING SHIFT LINK
97
SPINDLE , Replaced By: A1242650574
98
GASKET BEARING SPINDLE TO TRANSMISSION CASE
101
SEAL RING
103
SPRING WASHER LICENSE PLATE TO BRACKET
104
SCREW PUMP TO BRACKET
104
SCREW , Replaced By: N304017006016
119
SHIFT LEVER , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A1242603439
119
SHIFT LEVER , DURING ASSEMBLY UP TO TRANSMISSION 1 498499 ,REWORK THE OLD INTERMEDIATE PIECE 126 261 05 041 997650 EXCEPT FOR: 1 719698 - 1 794161, Replaced By: A1262601239, +001A1262602330
119
SHIFT LEVER , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO TRANSMISSION 1 498499, Replaced By: A1242603139
119
SHIFT LEVER , Replaced By: A2022600739, +001A1242600069
119
SHIFT LEVER 5TH SPEED AND REVERSE, DURING ASSEMBLY UP TO TRANSMISSION 1 450264,REWORK THE OLD INTERMEDIATE PIECE 124 261 07 04
121
SHIFT LEVER REVERSE SPEED
121
SHIFT LEVER , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A1262601139
121
SHIFT LEVER , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO TRANSMISSION 1 473976, Replaced By: A1262601039
123
SHIFT LEVER 5TH SPEED AND REVERSE
125
BUSHINGTO 201 260 12 39
127
STOP SLEEVE
129
SCREW , Replaced By: N000912008200
129
SCREW , Replaced By: N000912008219
129
SCREW SPRING STOP
131
BUSHING REVERSE SPEED INTERLOCK
133
SPRING , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO TRANSMISSION 6 277169, Replaced By: A1242600069
133
SPRING REVERSE SPEED INTERLOCK
135
PIN 5TH SPEED/REVERSE SHIFT LEVER TO INTERMEDIATE PLATE,6 268644
137
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
137
SPRING WASHER , Replaced By: N000137008212
139
NUT STEP TO APPARATUS SUPPORT
141
SHIFTING FORK 5TH SPEED SWINGING SHIFT LINK
141
SHIFTING FORK ,1 997650 EXCEPT FOR: 1 719698 - 1 794161, Replaced By: A1262602330, +001A1262601239
143
NEEDLE BEARING
143
NEEDLE BEARING
145
SHIFTING FORK 3RD AND 4TH SPEED, THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE
147
SPRING
149
SEAL RING , Replaced By: A0079970348
149
SEAL RING
151
SPINDLE , Replaced By: A1242650474
151
PIN 5TH SPEED SWINGING SHIFT LINK
153
SPRING WASHER LICENSE PLATE TO BRACKET
155
SCREW PUMP TO BRACKET
155
SCREW , Replaced By: N304017006016
