Поз.
Артикул
Описание
56
SHIFTING ROD (SHIFTING RAIL),SPLITTER BOX
59
SHIFTING FORK SPLITTER BOX
59
SHIFTING FORK , Replaced By: A0002653301
59
SHIFTING FORK , Replaced By: A0002653701
62
SLIDE , Replaced By: A0002680849
62
SLIDE SHIFTING FORK
65
THREADED PIN ADDITIONAL GEAR CLUSTER
65
STUD , Replaced By: A0002650575
68
SHIFTING CYLINDER , Replaced By: A0002670519
68
SHIFTING CYLINDER SPLITTER BOX
71
SEAL RING
74
BOOT SHIFTING SHAFT
74
BOOT , Replaced By: A0002670297
74
BOOT , Replaced By: A0002670697
77
PISTON , Replaced By: A0002670918
77
PISTON SHIFTING CYLINDER
77
PISTON SHIFTING CYLINDER
80
BOOT SHIFTING CYLINDER
80
SEAL RING , Replaced By: A0002670997
83
NUT , Replaced By: N913004016005
83
NUT , Replaced By: N913004016005
83
NUT , Replaced By: N910113016001
86
VALVE , Replaced By: A0012605957
86
VALVE SHIFTING CYLINDER
89
SEAL RING COVER TO TRANSMISSION CASE
92
SEAL RING COVER TO TRANSMISSION CASE
95
SCREW , Replaced By: N304017008053
98
SPRING WASHER , Replaced By: N000137008212
101
SCREW (THROTTLE SCREW)
104
SEAL RING LINE CONNECTION
107
DETENT SHIFTING ROD DETENT
107
DETENT , Replaced By: A0002601773
110
SEAL RINGTO 006 997 00 72
113
SPRING WASHER BRACKET TO TIMING CASE
116
SCREW PLUG BELL HOUSING
116
SCREW PLUG SHIFTING ROD DETENT
119
SEAL RING VALVE TO VALVE,K 025179
122
PIN ADDITIONAL GEAR CLUSTER
122
PIN , Replaced By: A0009976010
125
EXPANSION PLUG HOUSING,BOTTOM
128
SHIFTING FORK ,001043, Replaced By: A0012651905
128
SHIFTING ROD , EXHAUST STOCK OF OLD PARTS NUMBER FIRST FROM TRANSMISSION 004245-013418, Replaced By: A0002658605
128
SHIFTING ROD , Replaced By: A0012651405
128
SHIFTING ROD , Replaced By: A0012652005
128
SHIFTING ROD , Replaced By: A0012654405, +001A0002655702, +001A0002650170
128
SHIFTING ROD ADDITIONAL GEAR CLUSTER
128
SHIFTING ROD ADDITIONAL GEAR CLUSTER
131
SHIFTING FORK ADDITIONAL GEAR CLUSTER
134
THREADED PIN ADDITIONAL GEAR CLUSTER
134
STUD , Replaced By: A0002650575
137
SLIDE SHIFTING FORK
140
SCREW SHIFTING FORK TO SHIFTING SHAFT TO 000 265 27 01,004245
143
NUT STRAP TO SUPPORT,5 149419
146
BOOT SHIFTING SHAFT
146
BOOT , Replaced By: A0002670297
146
BOOT , Replaced By: A0002670697
149
PISTON ADDITIONAL GEAR CLUSTER
152
SEAL RING SHIFTING SHAFT
152
SEAL RING , Replaced By: A0119973047
152
SEAL RING , Replaced By: A0169973747
155
GUIDE , Replaced By: A0002671059
155
GUIDE SHIFTING SHAFT
158
NUT , Replaced By: N910113016001
158
NUT , Replaced By: N913004016005
158
NUT , Replaced By: N913004016005
161
SHIFTING CYLINDER HOUSING , Replaced By: A0002670419
161
SHIFTING CYLINDER HOUSING , Replaced By: A0002672119
161
SHIFTING CYLINDER , Replaced By: A0002670419
161
SHIFTING CYLINDER ADDITIONAL GEAR CLUSTER
164
BALL SHIFTING CYLINDER
167
SEAL RING SHIFTING CYLINDER
170
SEAL RING SHIFTING CYLINDER
170
SEAL RING , Replaced By: A0229970148
173
SCREW CLUTCH TO FLYWHEEL
176
SPRING WASHER STEERING COLUMN BRACKET TO CAB
179
DETENT SHIFTING ROD DETENT
179
DETENT , Replaced By: A0002601773
182
SPRING WASHER BRACKET TO TIMING CASE
185
SEAL RINGTO 006 997 00 72
188
SCREW PLUG
191
SEAL RING VALVE TO VALVE,K 025179
194
PIN ADDITIONAL GEAR CLUSTER
194
PIN , Replaced By: A0009976010
197
SNAP RING ADDITIONAL GEAR CLUSTER
