Поз.
Артикул
Описание
5
GASKET , Replaced By: A0002686180
56
PIN ,007520
56
PIN SHIFT CASE,007519
59
PIN TRANSMISSION CASE REAR COVER,SIDE 10X124.70 MM
59
PIN , Replaced By: A0002653674
68
EXPANSION PLUG ROD END
74
SCREW SUPPORT TO SIDE MEMBER M 10X65,B 884219
77
SCREW
77
SCREW RUBBER MOUNTING TO FRONT AXLE
77
SCREW BRACKET TO REAR CROSS MEMBER
89
SPRING WASHERTO 000 268 46 01
92
PIN INTERLOCK PIN
95
BUSHING SHIFT CASE,TOP
98
SPRING SHIFT CASE
110
ROLLER SHIFTING SHAFT
110
ROLLER , 350.004,013 UP TO CHASSIS 12 357727,FROM CHASSIS SEE SPARE PARTS LIST 718
113
CYLINDRICAL ROLLER SHIFTING SHAFT
116
FOLLOWER SHIFTING SHAFT
203
SPACER WASHER SHIFTING SHAFT
203
SPACER WASHER SHIFTING SHAFT
227
COVER LATERAL
236
GASKET SHIFT CASE,TOP AND BOTTOM
236
GASKET , Replaced By: A0002685180
239
GASKET , Replaced By: A0002685580
290
SCREW QUICK-RELEASE VALVE TO BRACKET
293
SCREWTO 376 131 74 01
293
SCREW POWER CYLINDER TO BEARING BRACKET
294
SCREW BRACKET MOUNTING
302
SPRING WASHER CABLE TO ALTERNATOR
308
SPRING WASHER CABLE TO ALTERNATOR
365
SPRING WASHER OUTPUT FLANGE TO P.T.O. SHAFT
