Поз.
Артикул
Описание
5
SHIFT CYLINDER
5
SHIFTING CYLINDER , Replaced By: A0002670519
5
SHIFTING CYLINDER SPLITTER BOX
8
VALVE , Replaced By: A0012605957
8
VALVE SPLITTER BOX
8
VALVE SPLITTER BOX HUNGER
11
GASKET KITTO 001 260 06 57,WABCO
14
BOOT SHIFTING CYLINDER
14
BOOT SHIFTING SHAFT
14
BOOT SHIFTING CYLINDER
14
BOOT , Replaced By: A0002670297
14
BOOT , Replaced By: A0002672097
17
PISTON SHIFTING CYLINDER
17
PISTON SHIFTING CYLINDER
17
PISTON SHIFTING CYLINDER
20
FASTENER FIXED PART OF JOINT TO 341 460 76 05,LEMFOERDER
20
SEAL RING , Replaced By: A0002670997
20
SEAL RING SHIFTING CYLINDER
23
NUT , Replaced By: N913004016005
26
SEAL RING COVER TO TRANSMISSION CASE
29
SEAL RING COVER TO TRANSMISSION CASE
32
SEAL RING
36
SCREW TRANSMISSION CASE COVER TO TRANSMISSION CASE, UP TO IDENT NO. 207851 FROM IDENT NO. 207852 SEE MICROFICHE MODEL 712.0
39
SPRING WASHER , Replaced By: N000137008212
42
SHIFTING CYLINDER PARTS KIT TO A0002670419
45
SHIFTING CYLINDER ADDITIONAL GEAR CLUSTER
45
SHIFTING CYLINDER HOUSING , Replaced By: A0002670419
45
SHIFTING CYLINDER HOUSING , Replaced By: A0002672119
45
SHIFTING CYLINDER , Replaced By: A0002670419
48
BOOT , Replaced By: A0002670297
48
BOOT , Replaced By: A0002672097
48
BOOT SHIFTING CYLINDER
48
BOOT SHIFTING CYLINDER
48
BOOT SHIFTING SHAFT
51
PISTON ADDITIONAL GEAR CLUSTER
54
SEAL RING , Replaced By: A0119973047
54
SEAL RING SHIFTING SHAFT
57
GUIDE SHIFTING SHAFT
57
GUIDE SHIFTING SHAFT
57
GUIDE SHIFTING SHAFT
57
GUIDE , Replaced By: A0002671059
57
GUIDE SHIFTING SHAFT
60
NUT , Replaced By: N913004016005
63
SEAL RING , Replaced By: A0229970148
66
SEAL RING SHIFTING CYLINDER
69
BALL SHIFTING CYLINDER
72
SCREW FENDER TO BRACKET, NOT USED
75
SPRING WASHERTO 000 268 46 01
