Поз.
Артикул
Описание
20
ROLLER BEARING MAIN SHAFT
29
MAIN SHAFT
32
LOCK AS REQUIRED 2.30 MM
32
LOCK AS REQUIRED 2.40 MM
32
LOCK ANNULUS, AS REQUIRED 4.00 MM
38
FOLLOWER CONSTANT
41
SYNCHRONIZER RING 3RD AND 4TH SPEED
44
SYNCHRONIZER BODY CONSTANT
47
SLIDING COLLAR 3RD AND 4TH SPEED
47
SLIDING COLLAR 3RD AND 4TH SPEED
50
SPRING 4TH AND 5TH SPEED,297251
53
END PIECE SYNCHRONIZER BODY
53
THRUST PIECE SYNCHRONIZER BODY
53
THRUST PIECE , Replaced By: A0002640839
62
NEEDLE BEARING 1ST SPEED GEAR
65
GEAR 4TH SPEED
68
SYNCHRONIZER RING , Replaced By: A0002626734
68
SYNCHRONIZER RING PLANETARY GEAR CLUSTER SHIFT
71
SYNCHRONIZER BODY 3RD AND 4TH SPEED
74
SLIDING COLLAR 3RD AND 4TH SPEED
80
BUSHING
83
FOLLOWER 3RD AND 4TH SPEED
86
NEEDLE BEARING 3RD SPEED GEAR
89
GEAR 3RD SPEED
89
GEAR , Replaced By: A0002629913
92
NEEDLE BEARING 3RD SPEED GEAR
95
GEAR 2ND SPEED
98
SYNCHRONIZER RING
98
SYNCHRONIZER RING
101
SYNCHRONIZER BODY 1ST AND 2ND SPEED
104
LOCK RING PRIMARY PUMP
104
LOCK GEAR, AS REQUIRED 2.60 MM
104
LOCK AS REQUIRED 2.70 MM
107
FOLLOWER 1ST AND 2ND SPEED
110
SLIDING COLLAR 1ST AND 2ND SPEED
113
NEEDLE BEARING 1ST SPEED GEAR
116
GEAR 1ST SPEED
119
FOLLOWER REVERSE SPEED
122
LOCK GEAR, AS REQUIRED 2.60 MM
122
LOCK MAINSHAFT, AS REQUIRED 2.80 MM
122
LOCK RING AS REQUIRED 2.50 MM
122
LOCK AS REQUIRED 2.70 MM
125
NEEDLE BEARING REVERSE SPEED GEAR
128
GEAR REVERSE SPEED
131
CYLINDR. ROLLER BEARING MAIN SHAFT,REAR
137
DRIVE GEAR SPEEDOMETER DRIVE
146
COUPLING FLANGE MAIN SHAFT OUTPUT
149
WASHER FLANGE TO MAIN SHAFT
150
SCREW FRONT EXHAUST PIPE TO EXHAUST MANIFOLD
153
LOCK , Replaced By: A3859941032
156
SCREW FOLLOWER FLANGE TO PROPELLER SHAFT
999
SPACER RING COUNTERSHAFT
