Поз.
Артикул
Описание
8
13
PROTECTIVE PLATE , Replaced By: A3834922530
15
HEX. HEAD. SCREW FRONT EXHAUST PIPE TO EXHAUST MANIFOLD
19
NUT STRAP TO SUPPORT,5 149419
23
FLANGE GASKET FRONT EXHAUST PIPE TO EXHAUST MANIFOLD, UP TO IDENT NO. 4 153178 EXCEPT FOR 515187-599999
27
CONNECTOR FRONT
32
CLAMP PIPE LINE TO PIPE LINE
35
77
EXHAUST MUFFLER WITH PIPE WITH FRONT PIPE,872788 IF REQUIRED, ALSO ORDER: 1 CONNECTOR, 240 MM LONG 352 492 09 07
77
EXHAUST MUFFLER WITH PIPE
92
CLAMP FROM FLEXIBLE METAL TUBE TO RESONATOR
92
CLAMP EXHAUST MUFFLER,REAR 63.5 MM
95
CLAMP REAR EXHAUST PIPE TO SUPPORT,D 250888
101
BRACKET ,A 006845
104
BRACKET ,A 006846A 043054
107
BRACKET ,A 006846A 043054
999
999
PROTECTIVE PLATE , Replaced By: A3834900330
999
