Поз.
Артикул
Описание
5
PUMP , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 162440, Replaced By: A0005502383
6
SEAL CONE , Replaced By: A0005550618
7
SCREW CONNECTION
8
HANDLE , Replaced By: A0005550440
9
NUT , Replaced By: A0005550372
10
BALL , UP TO CHASSIS 620000 EXCEPT FOR, 500001-599999
15
SPRING , Replaced By: A0005500955
17
SEAL RINGTO 000 550 00 83
20
FITTING , UP TO CHASSIS 620000 EXCEPT FOR 500001-599999
25
SEAL CONE , Replaced By: A0009949454
30
NUT , Replaced By: A0009949454
35
SEAL RING , Replaced By: A0005500955
40
SEAL RINGTO 000 550 00 83
45
WASHER , UP TO CHASSIS 620000 EXCEPT FOR, 500001-599999
50
STRAINER , UP TO CHASSIS 620000 EXCEPT FOR, 500001-599999
55
SNAP RING , UP TO CHASSIS 620000 EXCEPT FOR, 500001-599999
60
62
HOSE FUEL LINE, ORDER BY THE METER
63
CLIP FUEL LINE TO CAB CONSOLE
65
PRIMER CAPSULE PRIMING FUEL
65
PRIMER CAPSULE , Replaced By: A0005501404
70
SERRATED WASHER
75
NUT
80
SEAL CONE , Replaced By: A0005550618
85
NUT , Replaced By: A0009949454
90
BRACKET , UP TO CAB 108424
95
FILLING CYLINDER PRIMING FUEL
100
BRACKET STARTER PILOT PUMP TO WINDOW SILL
105
SHEET METAL SCREW BRACKET TO WINDOW LEVEL GIRDER
110
LOCK WASHER LINE MOUNTING
115
CAPSULE , ON SPECIAL REQUEST
120
CAPSULE BORER , Replaced By: A0005501004
999
PUMP , Replaced By: A0005501083
999
WASHER , ON SPECIAL REQUEST
999
HOSE , Replaced By: A3359972282
999
HOSE FROM HAND PUMP TO PRIMER CAPSULE
999
HOSE , Replaced By: A3359972282
