Поз.
Артикул
Описание
5
TRANSMISSION CASE COVER GEARSHIFT MECHANISM
8
GASKET LATERAL, WITH AK 6-90 UP TO TRANSMISSION 068147,WITH AK 6-80 UP TO TRANSMISSION 279573
8
GASKET , Replaced By: A0002650280
11
SCREW , Replaced By: N304017010050
11
SCREW MOUNTING AND RAIL TO LEAF SPRING
11
SCREW STRAP TO BRACKET
11
SCREW , Replaced By: N304014010004
11
SCREW CLUTCH TO FLYWHEEL
14
SPRING WASHER STEERING COLUMN BRACKET TO CAB
17
SHAFT (SHIFTING SHAFT), 044937,S 6-90 137432, AK 6-90
20
ROLLER SHIFTING SHAFT
23
COVER SHIFT LEVER TO TRANSMISSION
26
SHIFT LEVER
26
SHIFT LEVER , Replaced By: A0002682730
26
SHIFT LEVER , Replaced By: A0002684130
32
SCREW SHIFTING ROD TO JOINT
35
SPRING WASHER STEERING COLUMN BRACKET TO CAB
38
NUT , Replaced By: N304032010002
41
JOINT SHIFTING SHAFT,TOP
44
NUT JOINT TO LEVER
47
NUT , Replaced By: N308673014001
50
CONNECTOR SHIFTING TUBE TO SHIFT LEVER
53
JOINT TOP
53
JOINT , Replaced By: A0002686189
56
NUT BRACKET TO TELESCOPIC TUBE,K 142858
59
NUT PULL ROD
62
PULL ROD , TO BE ADAPTED DURING ASSEMBLY
65
NUT STRAP TO SUPPORT,5 149419
68
JOINT , Replaced By: A0002686289
68
JOINT BOTTOM
71
BRACKET BRACING,131010
80
SCREW , Replaced By: N304017008018
86
SPRING WASHER , Replaced By: N000137008212
95
FOLLOWER TOP
98
FOLLOWER SHIFTING SHAFT
101
SPACER RING SHIFTING SHAFT
104
CLAMPING SLEEVE FOLLOWER TO SHIFTING SHAFT
107
CLAMPING SLEEVE FOLLOWER TO SHIFTING SHAFT
110
SHIFTING SEGMENT SHIFTING SHAFT
113
SPACER WASHER SHIFTING SHAFT
116
SPRING SHIFTING SHAFT
119
LOCK SHIFTING SHAFT
122
BEARING COVER , Replaced By: A0002680634
122
COVER , Replaced By: A0002680134
122
BEARING COVER SHIFTING DOME
125
SCREW , Replaced By: A0099900101
125
SCREW , Replaced By: N000933008337
131
PIN SHIFT CASE,BOTTOM
134
SPRING SHIFT CASE
137
SPRING WASHER , Replaced By: N000137008212
143
VALVE BREATHER, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
146
NEEDLE BEARING REAR DRIVE SHAFT
149
BUSHING SHIFTING DOME,TOP
152
SEAL RING SHIFTING SHAFT
155
BOOT SHIFTING SHAFT
158
SCREW PLUG
161
DETENT , Replaced By: A0002601873
161
DETENT TRANSMISSION CASE
164
LOCK PLATE SHIFT CASE
167
EXPANSION PLUG HOUSING,BOTTOM
167
COVER , Replaced By: A0009971120
173
PLUG , Replaced By: A0009973435
173
PLUG , Replaced By: A0009977535
173
PLUG , Replaced By: A3529970032
173
COVER , Replaced By: A0009977535
173
SCREW PLUG BELL HOUSING
176
COVER SHIFT CASE,BOTTOM
176
COVER SHIFT CASE,BOTTOM
179
GASKET SHIFT CASE,TOP AND BOTTOM
179
GASKET , Replaced By: A0002685180
182
SHAFT SHIFT CASE
