Поз.
Артикул
Описание
349
SCREW VALVE TO BRACKET
349
SCREW VALVE TO BRACKET M 8X55
349
SCREW , Replaced By: N304017008018
349
SCREW , Replaced By: N304017008043
349
SCREW , Replaced By: N304017008028
349
SCREW , Replaced By: N304017006020
349
SCREW LICENSE PLATE TO BRACKET
349
SCREW SUPPORT TO FENDER
349
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
349
SCREW COVER PLATE TO BRACKET
350
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
350
WASHER , Replaced By: N000125008443
350
WASHER EXHAUST MUFFLER TO STRAP
350
WASHER COMPRESSED AIR LINE TO BRACKET
351
PLATE OIL DISTRIBUTION
351
PLATE OIL DISTRIBUTION
351
PLATE OIL DISTRIBUTION
351
PLATE OIL DISTRIBUTION
352
SCREW PLUG OIL DISTRIBUTION
353
PISTON
354
BALL
355
VALVE
355
VALVE
356
SNAP RING
357
OIL FILTER OIL DISTRIBUTION
358
PLATE OIL FILTER
359
SCREW , Replaced By: N304017006020
359
SCREW LICENSE PLATE TO BRACKET
360
INTERMEDIATE PLATE OIL DISTRIBUTION
360
INTERMEDIATE PLATE OIL DISTRIBUTION
360
INTERMEDIATE PLATE OIL DISTRIBUTION
442
VALVE (THROTTLE VALVE)
443
VALVE (THROTTLE VALVE)
444
PISTON
445
PISTON
446
PISTON
447
SPRING
448
BUSHING
448
BUSHING , Replaced By: A0002771250
449
LIFTING MAGNET , Replaced By: A0002772398
449
LIFTING MAGNET
450
SCREW HANDLE TO RATCHET ROD
450
SCREW SOLENOID VALVE TO VALVE
451
WASHER BOOT TO CAB FLOOR
451
WASHER , Replaced By: N000433005304
452
PISTON
453
PISTON
454
BALL
455
BALL
456
PISTON
457
PISTON
458
PLATE
459
COVER
460
GASKET
461
SCREW PUMP TO BRACKET
461
SCREW , Replaced By: N304017006016
461
SCREW COVER PLATE TO BRACKET
462
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
462
WASHER COMPRESSED AIR LINE TO BRACKET
463
OIL FILTER
463
OIL FILTER
464
PLATE
465
GASKET PLATE TO VALVE
466
SCREW APPARATUS PLATE M 6X45
467
WASHER COMPRESSED AIR LINE TO BRACKET
467
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
472
SCREW , Replaced By: N304017006027
472
SCREW APPARATUS PLATE M 6X45
473
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
473
WASHER COMPRESSED AIR LINE TO BRACKET
474
ELECTRIC CABLE , Replaced By: A0015462014
474
ELECTRIC CABLE
475
GASKET
476
SEAL RING PLUG SOCKET TO TRANSMISSION CASE
477
SCREW , Replaced By: N000933008337
477
SCREW , Replaced By: A0099900101
477
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
478
WASHER PLUG SOCKET TO TRANSMISSION CASE
479
WASHER EXHAUST MUFFLER TO STRAP
479
WASHER , Replaced By: N000125008443
480
CLAMP
481
LOOM TIE LINE MOUNTING 280 MM
482
WASHER
