Поз.
Артикул
Описание
95
SCREW PLUG FUEL TANK
95
SCREW PLUG , Replaced By: N007604014110
98
SEAL RING
116
SCREW SUPPORT TO FENDER
116
SCREW , Replaced By: N304017008018
122
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
122
SPRING WASHER , Replaced By: N000137008212
131
SCREW , Replaced By: N304017008018
131
SCREW SUPPORT TO FENDER
134
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
134
SPRING WASHER , Replaced By: N000137008212
143
BRACKET OIL COOLER TO TRANSMISSION CASE,SIDE
152
SPRING WASHER , Replaced By: N000137008212
152
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
155
SCREW , Replaced By: N304017008021
155
SCREW PIPE CLAMP
230
SENDER UNIT OIL TEMPERATURE
230
SENDER UNIT AT TRANSMISSION, ON 720.0 UP TO TRANSMISSION 005804,720.2 UP TO TRANSMISSION 000195,ON 720.3 UP TO TRANSMISSION 000042,FROM TRANSMISSION SEE UNIT
233
SEAL RINGTO 000 553 03 05,000 553 18 05,
