Поз.
Артикул
Описание
15
OIL SEPARATOR , FROM ENGINE 234538 YEAR OF MANUFACTURE 1992
15
OIL SEPARATOR , Replaced By: A0000185835
22
HOSE , Replaced By: A3520182182
29
CLAMP25-40X13 MM
29
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
36
CAP OIL REFILLING
36
CAP , Replaced By: A3440180168
36
COVER OIL FILLER NECK
43
GASKET , Replaced By: A1020180080
50
EXPANSION PLUG OIL FILLER NECK
50
EXPANSION PLUG , Replaced By: A3520100019
50
EXPANSION PLUG , Replaced By: A3660100019
57
INTAKE PIPE , Replaced By: A3521302801
57
INTAKE PIPE FROM CYLINDER HEAD COVER TO AIR COMPRESSOR
64
HOSE FROM HEATING PIPE AT ENGINE TO HEATING PIPE AT RADIATOR, ORDER BY THE METER
71
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
71
CLAMP , Replaced By: N000000000667
78
BRACKET , Replaced By: A3520186340
78
BRACKET GUIDE TUBE
85
SCREW
92
LOCK WASHER
92
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
99
BOLT. SCREW QUICK-RELEASE VALVE TO BRACKET
106
CLAMP HOSE TO BRACKET 25/20,5 206397
113
NUT TAIL LAMP TO BRACKET
120
AIR INTAKE PIPE TURBOCHARGER
120
AIR INTAKE PIPE TURBOCHARGER
127
SCREW PLUG RELAY VALVE,CONNECTIONS: "23"
127
SCREW PLUG AT TANK
134
SEAL RING POWER STEERING PUMP
999
OIL SEPARATOR
999
OIL SEPARATOR
999
SEAL RING OIL FILLER PIPE
999
CAP
999
INTAKE PIPE FROM CYLINDER HEAD COVER TO AIR COMPRESSOR
999
INTAKE PIPE FROM VACUUM PUMP TO OIL PAN
999
HOSE , Replaced By: N900271015069
999
BRACKET
999
OIL FILLER NECK
999
HOSE TURBOCHARGER
999
BRACKET BREATHER PIPE
999
CLAMP HOSE 70-90X13 MM
999
SCREWM 8X18
999
CLAMP , Replaced By: N000000000674
