Поз.
Артикул
Описание
131
VALVE BODY ASSEMBLY REGULATOR VALVE
134
SPRING LOCK-UP SHIFT VALVE 0.90X8.50X38 MM
137
PISTON LOCK-UP SHIFT VALVE
140
SHIFT VALVE LOCK-UP SHIFT VALVE
143
PIN LOCK-UP SHIFT VALVE
146
LOCK REGULATOR VALVE
149
SPRING SECOND BRAKE 0.60X9.50X31.4 MM
152
PISTON SECOND BRAKE
155
SHIFT VALVE SECOND BRAKE
155
VALVE SECOND BRAKE, FROM TRANSMISSION 015028 ALSO INSTALLED ON 014908,014913,014975,014994,014995,014998,015005 BUT NOT FOR AUSTRALIA016034
158
SPRING SECOND BRAKE 0.25X5.00X15.10 MM
161
PISTON SECOND BRAKE,000574
164
PISTON KICK-DOWN REDUCTION VALVE
167
PIN SECOND BRAKE
170
BUSHING WORKING PRESSURE, FROM TRANSMISSION 015028 ALSO INSTALLED ON 014908,014913,014975,014994,014995,014998,015005 BUT NOT FOR AUSTRALIA
173
PISTON WORKING PRESSURE
176
PISTON WORKING PRESSURE REGULATOR VALVE
179
BUSHING WORKING PRESSURE REGULATOR VALVE
182
SPRING WORKING PRESSURE 1.80X22.80X94 MM, FROM TRANSMISSION 015028 ALSO INSTALLED ON 014908,014913,014975,014994,014995,014998,015005 BUT NOT FOR AUSTRALIA
185
PIN WORKING PRESSURE REGULATOR VALVE
188
SHIFT VALVE CONVERTER RELAY VALVE
191
SPRING CONVERTER RELAY VALVE 1.10X14.20X28.10 MM
194
SHIFT VALVE DOWNSHIFT RELAY VALVE 2-1
197
SPRING DOWNSHIFT RELAY VALVE 2-1 0.80X11.30X28 MM
200
SPRING SHIFT VALVE 2-3 0.75X6.00X51.50 MM
203
SHIFT VALVE SHIFT VALVE 1-2
206
PIN SHIFT VALVE 1-2
209
PISTON FIRST BRAKE
212
SHIFT VALVE FIRST BRAKE
215
SPRING UPSHIFT RELAY VALVE 0.80X8.30X27 MM
218
SPRING RETAINER FIRST BRAKE
221
SPRING UPSHIFT RELAY VALVE 0.80X8.30X27 MM
224
PIN UPSHIFT RELAY VALVE
227
PISTON CONVERTER PRESSURE RELIEF VALVE
230
SPRING CONVERTER PRESSURE RELIEF VALVE 1.10X9.50X61 MM
239
BALL CONVERTER PRESSURE RELIEF VALVE
242
SPRING CONVERTER PRESSURE RELIEF VALVE 0.65X6.20X19.30 MM
245
PISTON SECONDARY PRESSURE REGULATOR VALVE
248
SPRING SECONDARY PRESSURE REGULATOR VALVE 0.80X8.50X75 MM
251
SPRING SECONDARY PRESSURE REGULATOR VALVE 1.60X12.20X64 MM
254
LOCKING SHEET
257
SCREW PROTECTION PLATE TO BRACKET
260
SPRING LOCK-UP COUPLING 0.32X6.64X27 MM
263
VALVE PART LOCK-UP COUPLING
266
SPRING LOCK-UP COUPLING 0.70X6.60X37.80 MM
269
VALVE BODY LOCK-UP COUPLING
269
VALVE LOCK-UP COUPLING TO 305 270 83 07,305 270 91 07
272
SCREWM 8X40
272
SCREW BRACKET TO CROSS CONNECTION STRUT
272
SCREW , Replaced By: N304017008034
275
SPRING WASHER , Replaced By: N000137008212
275
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
278
GASKET , Replaced By: A3052772080
278
GASKET FRONT
281
GASKET REAR
281
GASKET , Replaced By: A3052771980
284
SCREW , Replaced By: N304017008053
284
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL
287
SCREW VALVE TO BRACKET
290
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
290
SPRING WASHER , Replaced By: N000137008212
