Mercedes A9753380405 - РЫЧАГ РУЛЕВОГО МЕХАНИЗМА

VL 3/24 DC - 5,3 730.027

33 FRONT AXLE - 230 STEERING,KNUCKLES,TIE ROD IL. 2

Поз.
Артикул
Описание
77
A9753380701
STEERING ARM
80
N308676020003
SCREW CONTROL ARM TO BEARING BRACKET M 20X1.5X70
86
A9753380405
STEERING ARM LEFT STEERING KNUCKLE
86
A9753380206
STEERING ARM RIGHT STEERING KNUCKLE VL 3/23
92
N308765020004
SCREW STEERING ARM TO STEERING KNUCKLE M 20X1.5X100
100
A9753301403
TIE RODLEMFOERDER
100
A9753301303
TIE ROD , FIRST EXHAUST STOCK OF OLD PARTS UP TO FRONT AXLE 09.01, Replaced By: A9753301403
101
A0014606548
DRAG LINK END L.H. THREAD LEMFOERDER
102
A0003385445
CLAMP PARTS KIT LEMFOERDER
104
N308676010016
HEXAGON HEAD BOLTM10X1X50
107
N910113010003
NUT REINFORCEMENT TO BRACKET
108
A0004620734
SCREW COLLAR DRAG LINK END TO DRAG LINK
110
A0019905451
NUT DRAG LINK END M 24X1.5
