Поз.
Артикул
Описание
5
DIFFERENTIAL GEAR
8
PIN DIFFERENTIAL GEAR
11
DIFFERENTIAL SPIDER DIFFERENTIAL GEAR
20
SPHERICAL WASHER DIFFERENTIAL GEAR
26
HEXAGON HEAD BOLT VALVE TO BRACKET M8X65
28
PARTS KIT DRIVE PINION TO A 611 353 50 15,A 107 353 00 14
28
PARTS KIT DRIVE PINION
32
REPAIR KIT DIFFERENTIAL GEAR
35
SPACER WASHER AS REQUIRED, STEEL 1.30 MM
35
SPACER WASHER AS REQUIRED, STEEL 1.70 MM, TO A 667 353 00 15 , 02 15
35
THRUST WASHER AS REQUIRED 1.30 MM
35
THRUST WASHER AS REQUIRED 1.80 MM
35
SPACER WASHER AS REQUIRED, STEEL 1.80 MM
35
THRUST WASHER AS REQUIRED 1.60 MM
35
THRUST WASHER AS REQUIRED 1.40 MM
35
SPACER WASHER AS REQUIRED, STEEL 1.40 MM, TO A 667 353 00 15 , 02 15
35
SPACER WASHER AS REQUIRED, STEEL 1.50 MM
35
SPACER WASHER AS REQUIRED, STEEL 1.90 MM, TO A 667 353 00 15 , 02 15
35
SPACER WASHER AS REQUIRED, STEEL 1.60 MM
35
THRUST WASHER AS REQUIRED 1.50 MM
35
THRUST WASHER AS REQUIRED 1.70 MM
38
RING GEAR AND PINION RATIO: 37:9
41
SCREW RING GEAR TO DIFFERENTIAL CASE
44
TAPERED ROLLER BEARING RING GEAR BEARING
44
TAPERED ROLLER BEARING DIFFERENTIAL GEAR BEARING
47
SPACER WASHER AS REQUIRED 6.04 MM
47
SPACER WASHER AS REQUIRED 6.06MM
47
SPACER WASHER AS REQUIRED 5.40 MM
47
SPACER WASHER AS REQUIRED 5.76 MM
47
SPACER WASHER AS REQUIRED 6.00 MM
47
SPACER WASHER AS REQUIRED 5.42 MM
47
SPACER WASHER AS REQUIRED 6.08 MM
47
SPACER WASHER AS REQUIRED 5.54 MM
47
SPACER WASHER AS REQUIRED 5.72 MM
47
SPACER WASHER AS REQUIRED 6.12 MM
47
SPACER WASHER AS REQUIRED 5.12 MM
47
SPACER WASHER AS REQUIRED 5.52 MM
47
SPACER WASHER AS REQUIRED 5,94MM
47
SPACER WASHER AS REQUIRED 5.86MM
47
SPACER WASHER AS REQUIRED 5.96 MM
47
SPACER WASHER AS REQUIRED 5.02 MM
47
SPACER WASHER AS REQUIRED 5.74MM
47
SPACER WASHER AS REQUIRED 5.88 MM
47
SPACER WASHER AS REQUIRED 6.36 MM
47
SPACER WASHER AS REQUIRED 5.16 MM
47
SPACER WASHER AS REQUIRED 5.48 MM
47
SPACER WASHER AS REQUIRED 5.82MM
47
SPACER WASHER AS REQUIRED 6.16 MM
47
SPACER WASHER AS REQUIRED 6.02MM
47
SPACER WASHER AS REQUIRED 5.80 MM
47
SPACER WASHER AS REQUIRED 4.90 MM
47
SPACER WASHER AS REQUIRED 5.58 MM
47
SPACER WASHER AS REQUIRED 5.14MM
47
SPACER WASHER AS REQUIRED 5.68 MM
47
SPACER WASHER AS REQUIRED 5.22MM
47
SPACER WASHER AS REQUIRED 4.96 MM
47
SPACER WASHER AS REQUIRED 5.00 MM
47
SPACER WASHER AS REQUIRED 5.60 MM
47
SPACER WASHER AS REQUIRED 6.24 MM
47
SPACER WASHER AS REQUIRED 4.92 MM
47
SPACER WASHER AS REQUIRED 5.30MM
47
SPACER WASHER AS REQUIRED 5.32 MM
47
SPACER WASHER AS REQUIRED 5.84 MM
47
SPACER WASHER AS REQUIRED 5.20 MM
47
SPACER WASHER AS REQUIRED 5.24 MM
47
SPACER WASHER AS REQUIRED 5.06 MM
47
SPACER WASHER AS REQUIRED 5.56 MM
47
SPACER WASHER AS REQUIRED 5.26MM
47
SPACER WASHER AS REQUIRED 5.44 MM
47
SPACER WASHER AS REQUIRED 5.34MM
47
SPACER WASHER AS REQUIRED 5.36 MM
47
SPACER WASHER AS REQUIRED 5.46 MM
47
SPACER WASHER AS REQUIRED 6.28 MM
47
SPACER WASHER AS REQUIRED 5.50 MM
47
SPACER WASHER AS REQUIRED 5.70MM
47
SPACER WASHER AS REQUIRED 6.32 MM
47
SPACER WASHER AS REQUIRED 5.62 MM
47
SPACER WASHER AS REQUIRED 5.18MM
47
SPACER WASHER AS REQUIRED 5.66 MM
47
SPACER WASHER AS REQUIRED 6.20 MM
47
SPACER WASHER AS REQUIRED 5.28 MM
47
SPACER WASHER AS REQUIRED 5.64 MM
47
SPACER WASHER AS REQUIRED 5.90MM
47
SPACER WASHER AS REQUIRED 5.90MM, Replaced By: A6013536854
47
SPACER WASHER AS REQUIRED 4.92 MM, Replaced By: A6013537052
47
SPACER WASHER AS REQUIRED 4.96 MM, Replaced By: A6013537252
47
SPACER WASHER AS REQUIRED 5.02 MM, Replaced By: A6013537452
47
SPACER WASHER AS REQUIRED 5.06 MM, Replaced By: A6013537652
47
SPACER WASHER AS REQUIRED 5.12 MM, Replaced By: A6013537752
50
TAPERED ROLLER BEARING PINION,INSIDE
50
TAPERED ROLLER BEARING PINION,INSIDE
50
TAPERED ROLLER BEARING PINION,INSIDE
50
TAPERED ROLLER BEARING PINION,INSIDE
56
SPACER TUBE INSIDE DIAMETER X LENGTH: 34X21MM
56
SPACER BUSHING
59
OIL COLLECTOR PINION,INSIDE
62
RING
65
TAPERED ROLLER BEARING , Replaced By: A0029801102
65
TAPERED ROLLER BEARING PINION,OUTSIDE
71
SEAL RING PINION,OUTSIDE
71
SEAL RING , Replaced By: A0179975547
71
SEAL RING , Replaced By: A0179975547
71
SEAL RING , Replaced By: A0179975547
77
FLANGE , Replaced By: A4603530745, +001A4603530091
77
FLANGE100 MM
80
PROTECTIVE PLATE
83
NUT FLANGE TO PINION,R 067538
